Chemical products

Multi Gasket GREEN K161

• Ideal for sealing of narrow flanges and sealing faces having small
outlet openings and liquid channels
• Silicone-free
• Outstanding chemical resistance

Technical Data
Viscosity (25°C): 17.000 – 50.000 mPas
Density (25°C): 1.05 g/cm³
Temperature resistance: from -55 °C to +150 °C
Max. gap filling: 0.3 mm
Breakaway torque: 2 – 4 Nm
Shear strength (DIN 54452): 7 – 10 N/mm²
Touchable consistency: 20 – 40 min
Functional consistency: 3 – 6 h
Final consistency: 6 – 24 h
Pressure resistance: 300 bar

Article No. Article Description
6480 4510 GREEN MULTI GASKET K161 50G

Multi Gasket ORANGE K162

• Anerobic Gasket Compound when assembled
• Will not block oil ways
• Silicone-free
• Excellent chemical resistance

Technical Data
Viscosity (25°C): 30.000 – 100.000 mPas
Density (25°C): 1.1 g/cm³
Temperature resistance: from -55 °C to +150 °C
Max. gap filling: 0.5 mm
Breakaway torque: 5 – 8 Nm
Shear strength (DIN 54452): 5 – 10 N/mm²
Touchable consistency: 15 – 30 min
Functional consistency: 1 – 3 h
Final consistency: 6 – 24 h
Pressure resistance: 300 bar

Article No. Article Description
6480 4515 ORANGE MULTI GASKET K162 50G
