EPS FASADA (FAÇADE)

4 thermal insulation of external walls using the 4 thermal insulation of tie beams, lintels
ETICS method
4 thermal insulation of window frames
4 thermal insulation on the frame wall surface
4 thermal insulation of all layered walls
4 thermal insulation in the fissure of an enclosed
three-layered wall

λ – declared thermal conductivity coefficient
D
lambda [W/(m·K)].

EPS TERMONIUM PLUS fasada (façade) EPS GALAXY fasada (façade)

λ 0.031 W/(m·K) λ 0.033 W/(m·K)
D D

Declared thermal resistance R for selected TERMONIUM PLUS fasada (façade) boards Declared thermal resistance R for selected GALAXY fasada (façade) boards
D D
Thickness in mm 10 20 30 40 50 60 70 80 90 100 Thickness in mm 10 20 30 40 50 60 70 80 90 100
R , m K/W 0.30 0.60 0.95 1.25 1.60 1.90 2.25 2.55 2.90 3.20 R , m K/W 0.30 0.60 0.90 1.20 1.50 1.80 2.10 2.40 2.70 3.00
2
2
D
D
Thickness in mm 110 120 130 140 150 160 170 180 190 200 Thickness in mm 110 120 130 140 150 160 170 180 190 200
R , m K/W 3.50 3.85 4.15 4.50 4.80 5.15 5.45 5.80 6.10 6.45 R , m K/W 3.30 3.60 3.90 4.20 4.55 4.85 5.15 5.45 5.75 6.05
2
2
D D
EPS TERMONIUM fasada (façade) EPS GOLD fasada (façade)

λ 0.032 W/(m·K) λ 0.038 W/(m·K)
D
D

Declared thermal resistance R for selected TERMONIUM fasada (façade) boards Declared thermal resistance R for selected GOLD fasada (façade) boards
D D
Thickness in mm 10 20 30 40 50 60 70 80 90 100 Thickness in mm 10 20 30 40 50 60 70 80 90 100
STYROPIAN
R , m K/W 0.30 0.60 0.90 1.25 1.55 1.85 2.15 2.50 2.80 3.10 R , m K/W 0.25 0.50 0.75 1.05 1.30 1.55 1.80 2.10 2.35 2.60
2
2
D D
Thickness in mm 110 120 130 140 150 160 170 180 190 200 Thickness in mm 110 120 130 140 150 160 170 180 190 200
2
2
R , m K/W 3.40 3.75 4.05 4.35 4.65 5.00 5.30 5.60 5.90 6.25 R , m K/W 2.85 3.15 3.40 3.65 3.90 4.20 4.45 4.70 5.00 5.25
D
D
EXTERNAL THERMAL INSULATION COMPOSITE SYSTEM EPS PLASTERS PAINTS ADHESIVES 7
