EPS FOR FOUNDATIONS
EPS GOLD dach – podłoga (roof-floor)

λ 0.036 W/(m·K)
D
Service load 3000 kG/m 2
CS(10) 100 kPa 4 thermal insulation of walls sunk in the ground 4 insulation of significantly damped places where
EPS 100 the insulation material has to be water resistant
4 thermal insulation of basement and foundation
walls

Declared thermal resistance R for selected GOLD dach-podłoga (roof-floor) boards
D λ – declared thermal conductivity coefficient lambda Service load w kG/m – evenly spread design load at which
2
D
Thickness in mm 10 20 30 40 50 60 70 80 90 100 [W/(m·K)]. relative creep strain after 50 years does not exceed 2%.
2
R , m K/W 0.25 0.55 0.80 1.10 1.35 1.65 1.90 2.20 2.50 2.75
D CS(10) – CS(10) – compression strength at 10% relative WL(T) – water absorbability with long-term (28-day) total
Thickness in mm 110 120 130 140 150 160 170 180 190 200 strain. submersion.
R , m K/W 3.05 3.30 3.60 3.85 4.15 4.40 4.70 5.00 5.25 5.55
2
D
EPS SILVER dach – podłoga (roof-floor) EPS TERMONIUM PLUS fundament (foundation)

λ 0.031 W/(m·K)
D
λ 0.037 W/(m·K) Service load 4500 kG/m²
D
Service load 2400 kG/m 2 CS(10) 150 kPa
CS(10) 80 kPa EPS 150
EPS 80 WL(T) ≤ 4%

Declared thermal resistance R for selected SILVER dach-podłoga (roof-floor) boards Declared thermal resistance R for selected TERMONIUM PLUS fundament (foundation) boards
D D
Thickness in mm 10 20 30 40 50 60 70 80 90 100 Thickness in mm 10 20 30 40 50 60 70 80 90 100
2
R , m K/W 0.25 0.50 0.80 1.05 1.35 1.60 1.85 2.15 2.40 2.70 R , m K/W 0.30 0.60 0.95 1.25 1.60 1.90 2.25 2.55 2.90 3.20
2
D
D
Thickness in mm 110 120 130 140 150 160 170 180 190 200 Thickness in mm 110 120 130 140 150 160 170 180 190 200
R , m K/W 2.95 3.20 3.50 3.75 4.05 4.30 4.55 4.85 5.10 5.40 R , m K/W 3.50 3.85 4.15 4.50 4.80 5.15 5.45 5.80 6.10 6.45
2
2
D D
EPS DALMATYŃCZYK dach – podłoga (roof-floor) EPS TERMONIUM fundament (foundation)

λ 0.031 W/(m·K)
λ 0.040 W/(m·K) D
D Service load 3000 kG/m 2
Service load 1800 kG/m 2 CS(10) 100 kPa
CS(10) 60 kPa EPS 100
EPS 60
WL(T) ≤ 3.5%

Declared thermal resistance R for selected DALMATYŃCZYK dach-podłoga (roof-floor) boards Declared thermal resistance R for selected TERMONIUM fundament (foundation) boards
D
D
Thickness in mm 10 20 30 40 50 60 70 80 90 100 Thickness in mm 10 20 30 40 50 60 70 80 90 100
2
R , m K/W 0.25 0.50 0.75 1.00 1.25 1.50 1.75 2.00 2.25 2.50 R , m K/W 0.30 0.60 0.95 1.25 1.60 1.90 2.25 2.55 2.90 3.20
2
D
D
Thickness in mm 110 120 130 140 150 160 170 180 190 200
Thickness in mm 110 120 130 140 150 160 170 180 190 200
2
R , m K/W 2.75 3.00 3.25 3.50 3.75 4.00 4.25 4.50 4.75 5.00 R , m K/W 3.50 3.85 4.15 4.50 4.80 5.15 5.45 5.80 6.10 6.45
2
D
D
EPS
