P. 12
MicroReg &
MicroReg Plus
Examples of applications
Installed at the fuel cell inlet,
MicroReg enables stable supply of
hydrogen on a large speed range. It
naturally finds its place in the system
This regulation function can also be
used for other scientific purposes.
Alpha bicycle
Technical specifications
MICROREG RANGE
This product as any product from MicroReg MicroReg Plus
Ad-Venta includes the know-how, Dimensions Ø32 x h 26 mm Ø50 x h 26 mm
the experience and the quality Weight Less than 50g Less than 70g
which characterize the product Material Aluminium Aluminium
offering from the company.
Supported by an I P portfolio, result Gas Hydrogen (All non-corrosives gases)
of a corporate culture of Inlet pressure Up to 20 bar Up to 20 bar
innovation, Ad-Venta and its Outlet pressure 0,5 bar and 3 bar 0,65 bar
products have been successfully Flowrate 300 SL/min (≈20 kW 500 SL/min (≈33kW fuel
associated or integrated into fuel cell) cell)
multiple products or projects. Operating ranges -10°C / +40°C
Input/output Thread G 1/4ʺ
Pressure stability
This product information is intended for information only and is subject to change without notice. It is not binding in any way our responsibility.
Version 1.1 EN, 06/06/2016
www.ad-venta.com
