ELECTRICAL



          Accessories




          DIN Socket                                          USB type "A" Twin Power Socket —
                                                              Illuminated blue
    ELECTRICAL
          „  366 Series, high quality DIN power socket with nylon body
            and rubber protective cap.                        „  366 Series, dual USB charge socket delivering high power
                                                                output 12/24 volt with blue illumination.
                                                              „  Nylon body and PC lens
                                                              „  Hidden screw fixing
                                                              „  Output 2.00 amps @ 5 volts
                                                              „  Output socket a) 1 amp
    EMERGENCY
                                                              „  Output socket b) 1 amp





    GENERAL







    HANDLES

         Part No.  A  B   C  D                     Kg  Voltage  Part No.  A  B  C  D                   Kg  Voltage

         366-3    37  29  35  86                  0.025 12/24v  366-11  56  30  29  46                0.045 12/24v

          Voltmeter — Illuminated blue LED
    HINGES
                                                                                SUN BLINDS
          „  Often used to check the state of the main or auxiliary battery.
          „  Can be mounted to the 366 series of faceplates and housings
            as shown below                                                      WE CAN PRODUCE SUN
                                                                                BLINDS TO VIRTUALLY
                                                                                ANY SIZE OR MATERIAL
    IRONWORK
                                                                                SPECIFICATION.



                                                                More info online
    LIGHTING






    LOCKS







    STEPS






         Part No.  A  B   C                        Kg  Voltage
         366-12   37  29  30                      0.015 12/24v               See page 49
    VENTILATION
