STEPS



          Sliding Steps




          Sliding Step — 3 Rung with Platform                 Sliding Step — 3 Rung

    ELECTRICAL
          „  Three rung pull out ladder with additional platform.  „  Three rung pull out ladder.
          „  The step is  Powder coated yellow.               „  The step is  Powder coated yellow.
          „  Supplied complete with fixing points and auto-lock as   „  Supplied complete with fixing points and auto-lock as
            standard.                                           standard.



    EMERGENCY







    GENERAL







    HANDLES

         Part No.  A  B   C  D   E   F   G  H      Kg  Finish  Part No.  A  B  C  D   E  F   G         Kg  Finish

         6133PY  900 388  65  846 267 330 250 330  15.42  ZP  6133Y   713 370  45  678 240 230 380     7.85  ZP

    HINGES
                                  RIGHT FIRST TIME   EVERY TIME





          Sliding Step — 2 Rung with Platform                 Sliding Step — 2 Rung
    IRONWORK
          „  Two rung pull out ladder with additional platform.  „  Two Rung Pull Out Ladder.
          „  The step is  Powder coated yellow.               „  The step is powder coated yellow.
          „  Supplied complete with fixing points and auto-lock as   „  Supplied complete with fixing points and auto-lock as
            standard.                                           standard.

    LIGHTING






    LOCKS







    STEPS



         Part No.  A  B   C  D   E   F   G  H      Kg  Finish  Part No.  A  B  C  D   E  F   G         Kg  Finish
         6132PY  815 388  65  584 267 230 250 330  12.75  ZP  6132Y   612 390  45  578 260 185 360    6.715  ZP
