P. 188

STEPS



          Cassette Steps




          Electric Cassette Steps — with override             Manual Cassette Step — with centralised
          function                                            pedal
    ELECTRICAL
          „  An electrically operated cassette step that incorporates a bi-  „  Activated by a foot pedal and deployed by a Gas Strut
            directional manual release system which allows the step to be   (0966RT), the step is simply pushed back in with the foot.
            deployed or stowed in the event of a power failure.
                                                              „  Supplied with buzzer and microswitch.
          „  Kit includes as standard, a buzzer, LED dash light, handbrake   „  Universal fitting kit included.
            override, step out warning, obstruction failsafe with auto-
            retract, built in illumination and Universal fitting kit.   „  Treadplate Depth 280mm
    EMERGENCY
          „  Treadplate Depth 280mm                           „  3 year warranty
          „  3 year warranty





    GENERAL







    HANDLES


         Part No.  A  B   C  D   E                 Kg  Finish
         6140-1A  73  688 435  78  608            19.98  GA
         6140-2   70  538 435  82  458             18   GA    Part No.  A  B  C   D   E                Kg  Finish
    HINGES
         6140-3   73 1285 435  82 1205             37   GA    6139-1  73  688 435  78  608            19.06  GA

          Electric Pantograph Step 600mm                      New Stem Cassette Step 600mm


          „  A new design of step that works on a pantograph mechanism.   „  An electrically operated cassette step that incorporates a bi-
            This provides an ideal solution where there is a requirement   directional manual release system which allows the step to be
    IRONWORK
            to bridge the gap between the ground and the entrance to   deployed or stowed in the event of a power failure.
            the vehicle.                                      „  Kit includes as standard, a buzzer, LED dash light, handbrake
          „  The solution comes from the mechanism that lowers the   override, step out warning, obstruction failsafe, built in
            treadplate by 80m when deploying. Class leading weight of   illumination and Universal fitting kit.
            13kg. It also has an inbuilt design feature that allows the step   „  Treadplate Depth 290mm.
            to be opened & closed manually in the unlikely event of a
            power failure.                                    „  3 year warranty.
    LIGHTING
          „  Ideal for recreational vehicles





    LOCKS







    STEPS





         Part No.  A  B   C  D   E                 Kg  Voltage  Part No.  A  B  C  D  E                Kg  Voltage
         6144    420 640 118  85  325             12.385  12v  6145   64  700 465  68  620            16.18  12v

    VENTILATION

    186      14th Edition         Innovation and development since 1756
