Reflectors

Rectangular Red Reflector — Screw Fixing PRODUCT FOCUS

ELECTRICAL
„ Red Rectangular Reflector 90mm x 40mm
„ Manufactured in PMA and ABS
„ Screw fixing.
„ ℮ Marked

E A
EMERGENCY
More info online
D

Part No. A B C D E Kg Finish
B C
GENERAL
8845R 40 90 7 70 4 0.025 RP

Rectangular Amber Reflector — Screw Rectangular White Reflector — Screw
Fixing Fixing

„ Amber Rectangular Reflector „ Screw fixing. „ White Rectangular Reflector „ Screw fixing.
HANDLES
90mm x 40mm. „ ℮ Marked 90mm x 40mm „ ℮ Marked
„ Manufactured in PMA and „ Manufactured in PMA and

ABS. ABS

HINGES
E A E A

D D

B C B C

IRONWORK
Part No. A B C D E Kg Finish Part No. A B C D E Kg Finish
8845A 40 90 7 70 4 0.025 AP 8845W 40 90 7 70 4 0.025 RP

Triangular Reflector — Black Frame - Screw Triangular Reflector — White Frame -
Fixing Screw Fixing
LIGHTING
„ Triangular Red Reflector with „ Screw fixing. „ Triangular Red Reflector with „ Screw fixing.
black frame and base. white frame and base.
„ ℮ Marked „ ℮ Marked
„ Manufactured in PMA and „ Manufactured in PMA and
ABS ABS
LOCKS

A D A D

E E
STEPS
B B
C F C F

Part No. A B C D E F Kg Finish Part No. A B C D E F Kg Finish
8844RB 132 132 8 67 33 7 0.065 RP 8844RW 132 132 8 67 33 7 0.065 RP
