GENERAL



           Bus & Coach Fittings

                                                                                                                     ELECTRICAL

           Drivers Sun Visor                                   Drivers Night Blinds

           „  Scissors action blind locks in required position  „  NB Dimension ‘A’ includes end brackets.
           „  Other sizes available to special order to a maximum width of   „  Spring loaded night blinds with a grain finish circular roller
             1000mm                                              housing.
           „  Please note that the drop (measurement C) must always be at   „  Supplied with end brackets for side fixing.
             least 200mm less than the width (measurement A)                                                         EMERGENCY
                                                               „  The blind material is dense black and the pull tab has integral
           „  Brackets allow for side or roof fitting            locating pin fixing.
           „  Bracket fixing hole centres = 34mm               „  Other widths and drops are available to special order.

                                                                                                                     GENERAL








                                                                                                                     HANDLES







                                                                                                                     HINGES


          Part No.  A  B   C  D   E                 Kg  Finish
          563-1   900 883 440  45  820             1.325  GP

                                                               Part No.  A  B                           Kg  Finish
           Netting                                             562-1   460 1090                         0.7  BP
                                                               562-3   610 1090                         0.9  BP      IRONWORK
           „  Fixing clips are designed to suit the profile of the cord and
             have one fixing hole per clip.
           „  The elasticated cord is run around the perimeter of the   Magazine Nets
             netting once it has been cut to required size.
                                                                                                                     LIGHTING
                                                               „  Metal frame.







                                                                                                                     LOCKS







                                                                                                                     STEPS





          Part No.  A   B          Description      Kg  Finish
          2106-1  10Mtr  1  10Mtr x 1Mtr x 25mm squares   3.115  B
                          luggage netting
                                                               Part No.  A  B                           Kg  Finish   VENTILATION
          2106-2          Pack of 25 Mtr’s elastic cord and 50  0.265  B
                          fixing clips                         620E881  360 220                         0.16  B


                                  +44 (0) 1454 319524     sales@stedall.co.uk     www.stedall.co.uk               49
