GENERAL



          Step Edging




          Stedlite Edge Strip                                 Lo-Step Carrier

    ELECTRICAL
          „  Anodised alluminium step edge supplied with inbuilt   „  Low profile self colour aluminium carrier - DDA compliant.
            polycarbonate diffuser designed to be used in conjunction   „  Underside serrated for increased grip.
            with the 578 series of flexible led strips and anti slip tape.
                                                              „  Takes flexible self adhesive non-slip insert (Part No. SVF1563).
          „  269-15 Yellow 15mm Wide Anti-Slip Tape.
                                                              „  Supplied in 3 metre lengths.
          „  Easy Clean Grain Rubber Finish.
          „  269-15B Black 15mm Wide Anti-Slip Tape.
          „  Easy clean.  Supplied in 5 metre lengths.
    EMERGENCY






    GENERAL







    HANDLES

         Part No.  A  B   C  D                     Kg  Finish  Part No.  A  B  C  D   E                Kg  Finish

         SVF1591  48  35  15  7                   1.68  AL    SVF1564  54  49  3  25  1.5             0.885  AL

          Lo-Step Insert                                      Recessed Aluminium Extrusion & Lens
    HINGES
          „  Self adhesive flexible insert for Lo-Step Carrier  „  3 meter recessed aluminium extrusion with light diffuser
          „  See Part No. SVF1564                               which is designed to take the 578 series of flexible self
                                                                adhesive LED strip lights.
          „  Supplied in 36 metre coils
          „  High Visibility Yellow.
          „  A sharks tooth option is available against part number
    IRONWORK
            SVF1560 Yellow Black Insert AKA Tiger Tooth.





    LIGHTING






    LOCKS




         Part No.  A  B                            Kg  Finish  Part No.  A  B  C                       Kg  Finish
         SVF1563  49  2                           4.955  HVY  SVF1585  25  13.5  7                    0.375  AL
    STEPS
          Looking for....


          Padlockable Handle?                                                                See page 69
