HANDLES

Handrail Fittings

Handrail Tubes — PVC Coated Handrail Fittings

ELECTRICAL
„ Supplied in 3 metre lengths „ 4 way connector – 2 part set
„ Coating – Yellow PVC „ Material: Reinforced polyamide
„ Unlike painted handrail it can be bent to shape and doesn’t „ Supplied complete with stainless steel clamping screws
chip

EMERGENCY
B C
A

A D
B
GENERAL

HANDLES
Part No. A B Kg Finish Part No. A B C D Kg Finish
6170-19 30 3 4.17 YP 6170-9 128 50 50 30 0.115 BP

6170-20 35 3 4.875 YP 6170-10 128 55 55 35 0.185 BP

Handrail Fittings Handrail Fittings
HINGES

„ Oval end socket. „ Tee connector – 2 part set.
„ Material: Reinforced polyamide. „ Material: Reinforced polyamide.
„ Supplied complete with stainless steel clamping screw. „ Supplied complete with stainless steel clamping screws.

IRONWORK
A B D

A
LIGHTING
C
D
C
B

LOCKS

Part No. A B C D Kg Finish Part No. A B C D Kg Finish
6170-5 90 42 66 30 0.05 BP 6170-7 89 50 50 30 0.095 BP
6170-6 90 42 66 35 0.04 BP 6170-8 89 55 55 35 0.085 BP
STEPS
