HANDLES



          Grab Handles




          Chest Handle — Stainless Steel                      Recessed Drop Handle

    ELECTRICAL
                                                              „  20497 - Diecast black powder coated body and handle.
                                                              „  20497-1 Sandblasted body and handle
                                                              „  Spring loaded (soft close) handle in both open and closed
                                                                positions



    EMERGENCY







    GENERAL







    HANDLES
                                                              Part No.  A  B  C   D   E                Kg  Finish
         Part No.  A   B   C   D   E               Kg  Finish  20497  110  70  13  99  58              0.23  B

         0719 20437  91  38  53  27  120          0.14  SS    20497-1  110  70  13  99  58             0.23  CH

          Sliding Door Handle                                 Recessed Door Pull Handle
    HINGES

          „  Material: Glass Fibre Polyamide                  „  Flush mounted door pull with return spring. Handle has black
          „  6mm countersunk fixing holes                       PVC sleeve.
                                                              „  Fixing holes: 5mm
                                                              „  Depth: 10mm

    IRONWORK






    LIGHTING
                                             A                           A


                                    B                   C
                                                               B                   C
                                              D
    LOCKS
                                                       E
                                                                         D
                                              F
         Part No.  A  B   C  D   E   F             Kg  Finish  Part No.  A  B  C   D                   Kg  Finish
         9-01390  133  60  41  114  21  95        0.45  BP    0719 20397  162  60  112  90             0.4  SS
    STEPS
          Looking for....


          Lock Strikers?                                                                     See page 153
