HANDLES



           Locking Handles

                                                                                                                     ELECTRICAL

           Padlockable Handle                                    PRODUCT FOCUS

           „  New sleek modern design with rounded handle for
             better comfort.
           „  Superior finish in 304 grade Stainless Steel.
           „  Greater Clearance to allow for larger padlock.
                                                                                 A                                   EMERGENCY
                                                                  B
                                                                                               More info online

                                                                  C
                                                                                                                     GENERAL
                                                                         D         E


                                                                  F
                                                                         G
                                                                                                                     HANDLES
          Part No.  A  B   C  D   E   F   G         Kg  Finish
          SVF9400  155  43  76  70  117  38  49     0.45  SS


           Locking Handle — Push Button                        Push Button Locking Handle

           „  3 off M6 threaded inserts on underside of handle.  „  2 off M6 threaded inserts on underside of handle.
           „  Keyed alike.                                     „  Use with Part No. 4790 GNS gasket set.             HINGES
                                                               „  Keyed alike.



                                                                                                                     IRONWORK







                                                                                                                     LIGHTING








                                                                                                                     LOCKS
          Part No.  A  B   C  D   E                 Kg  Finish  Part No.  A  B  C  D   E                Kg  Finish
          4791     37  180 120  50  37              0.2  BP    4790    40  180 119  55  40              0.17  BP


           Handle Gasket Set


           „  Rubber gasket set for use with                                                                         STEPS
             Part No. 4790 handle.


                                                                                                                     VENTILATION


          Part No.  A  B   C  D   E                 Kg  Finish
          4790GNS  50  65  21  23  22              0.005  BR
