Page 122 - Kit LUMIS CHU de RENNES Intervention le 16-03-2017
P. 122
Pedicle Preparation & Screw Insertion
Insert the screw with the screwdriver/screw
extension construct over the guide wire. Once the
screw is advanced far enough into the vertebral
body, it is recommended to remove the guide wire
to prevent any breach of the anterior wall.
The screw can then be fully inserted.
GMS2-ST_04GB See package insert for labeling limitation 28
