Pedicle Preparation & Screw Insertion
Attach the screw extender (MS1-A211/MS1-A214) to the screw (MS2-
MxxxT) by sliding down the locking ring down (1) and locking the assembly
by screwing the nut clockwise (2).
Laser markings indicate when the locking ring is in the locked position.
GMS2-ST_04GB See package insert for labeling limitation 26
