Rod Length Measurement
Rod length: 50 mm
Once all screws are placed, rotate the
extender sleeve so that the slots line up in
the sagittal plane.
The rod gauge (MS1-A261) is inserted into
the screw extenders until the ball tips rest in
the heads of the pedicle screws.
The rod length needed is indicated on top of
the rod gauge.
GMS2-ST_04GB See package insert for labeling limitation 31
