Final Tightening
(percutaneous)
Pre-assemble the instruments for the final tightening.
-MS1-A432 + U1-A622 (A)
(B)
-MS1-A411 + MS1-A421 (B)
Place the counter torque into the (A)
screw extender and insert the T30
shaft to tighten the set screw.
Final locking is achieved by
applying a 8.5N.m torque.
GMS2-ST_04GB See package insert for labeling limitation 52
