P. 35

LED LAMP



                VIVID Series








          VIV-T8DF2

                                                                                                                   COMPLIANT
          Features & Benefits                                                                Dimensional drawing
           DLC approved                           180° beam angle
           All glass construction , aluminium end caps  50,000 hour life (L70)
           13W with 1900lm (NBF) for 5000K        Instant on with no warm-up time
           High CRI (82+)                         Compatible with most Instant Start Ballast & Rapid   M.O.L.
           Direct replacement for T8 linear fluorescent  Start Ballast* with input voltage of 120-277V and 347V
          Warranty & Cautions

           5-year limited warranty (not recommended to use with ballast 5 years or older)
           Operating temperature range between -20˚C and +45˚C
           Sockets must be shunted
          *For detail, you may contact your sales person or check www.turolight.com for ballast compatibility list.
          Product Specification

                                   Nominal
           Ordering   DLC  Model Number  Lamp Power   System Power (Watts)  Initial Lumen (lm)  Base  Hour   Beam       CCT(K) CRI  M.O.L.  Case
            Code                   (Watts)  Low BF   Normal BF   High BF   Low BF   Normal BF   High BF   Rating  Angle  (inch)  QTY.
                                                                           (0.88)
                                                   (0.88)
                                            (0.78)
                                                                   (0.78)
                                                                                  (1.16)
                                                           (1.16)
           1732409  Y  VIV-T8DF2/13W/40/F  13  13   17      23     1400    1800    2500  G13   50,000   180°  4000  82  48  25
           1732506  Y  VIV-T8DF2/13W/50/F  13  13   17      23     1450    1900    2600  G13   50,000   180°  5000  82  48  25















          Ordering Information Example: VIV-T8DF2/13W/40/F
           LED CLASS LAMP TYPE  DIRECT FIT  WATTAGE  CCT(K)  FROST
            VIV   T8    DF2 (Direct Fit, 2 nd  version)  13W  40 (4000K)  F (Frost)
            (Vivid)                        50 (5000K)





          page 1 of 1, A18                                Tel: (416) 736-0447 • Toll Free: 1 (877) 736-0447 • Fax: (416) 736-4890 • Email: info@turolight.com • Website: www.turolight.com
