Testing & Calibration

Testing & Calibration of Chart Recorders and Pressure Gauges:
Our equipment is rated up to 2600 bar. Currently in Ghana we could test
with

Hydraulic Dead-Weight Tester: DH-Budenberg 580 EHX
• 580 EHX base with: 1 to 2600 bar (10 to 40,000 lb/in2) / Tester Serial
#: 31082
• Weight Set #: B1268 / Range: 10 to 30,000 lb/in2

Comparison Test Pump: WIKA CPP 1600-X Serial #: 70667
• Process Calibrator: CPH6000
• Pressure Sensors CPT6000 / Ranges: 100 bar, 1000 bar, 1600 bar,

2500 bar

Testing & Calibration of Torque Tools / Wreches:

NORBAR / TWL 1500 Torque Wrench Loader / Minimum
output torque – 1 Nm / Maximum output torque – 1500
Nm Dimensions: LxWxH – 1720 mm x 730 mm x 345 mm

Testing & Calibration of Digital Calipers, various
Micrometers, Depth Gauges, OD Setting Bars:

2x Sets of Equipment
Grade 1 Tungsten Carbide Gauge Block Set / serial number
P6946
