Keynote List
TRS (Technical Reference Schedule) Content (integrated and coordinated with e-specs & Revit Central)
Project
Keynote Value Short Form Description Division User Initial Use 315/325 Front Google BV Google CE Description:
Keynote Tag No. Location, Basis of Design, Material Description, Manufacturers, Alternates, Other info, etc
Toronto California California
LEED Platinum LEED LEED
05 50 00.D22 TILT UP DOOR TRACK AND OPERATOR ANCHORAGE 05
05 50 00.E1 LATERAL SUPPORT FOR MASONRY WALL 05
05 50 00.F2 SUMP PIT COVER PLATE 05
05 50 00.G1 CONCRETE FILLED GALVANIZED STEEL BOLLARD 05
05 50 00.G2 GALVANIZED STEEL BOLLARD 05
05 50 00.G3 REMOVABLE GALVANIZED STEEL BOLLARD 05
05 50 00.H11 GALVANIZED STEEL ANGLE CORNER GUARD 05
05 50 00.H12 STAINLESS STEEL CORNER GUARD 05
05 50 00.H2 LOADING DOCK EDGE PROTECTION 05
05 50 00.J1 GALVANIZED STEEL GUARDRAIL, WELDED 05
05 50 00.J10 STAINLESS STEEL CANE DETECTION RAIL 05
05 50 00.J11 PAINTED STEEL CANE DETECTION RAIL 05
05 50 00.J12 PT GALV CANE DETECTION RAIL 05
05 50 00.J15 CANE DETECTION CABLE 05
05 50 00.J2 PAINTED STEEL GUARDRAIL, WELDED 05
05 50 00.J20 PAINTED GALVANIZED STEEL GATE 05
05 50 00.J22 STEEL GATE FRAMING 05
05 50 00.J5 PAINTED STEEL GUARDRAIL, BOLTED 05
05 50 00.J6 PAINTED GALVANIZED STEEL GUARDRAIL, BOLTED 05
05 50 00.K1 VANITY SUPPORTS 05
05 50 00.K3 ROOF UP-LIGHT SUPPORTS 05
05 50 00.L1 BIRD MESH 05
05 50 00.M1 STEEL SUPPORTS FOR CLT 05
05 50 00.M10 GALV STEEL BENT PLATE BRACKET SUPPORTS FOR STRINGER 05
05 50 00.M2 STEEL DIAGONAL BRACING 05
05 50 00.M20 STEEL WEB CLOSURE PLATE 05
05 50 00.M21 PRE-FINISHED BENT METAL COVER PLATE 05
05 50 00.M3 STEEL CLT BEARING PLATE 05
05 50 00.M30 SUPPORTS FOR RECEPTION DESK MILLWORK 05
05 50 00.M5 GALVANIZED STEEL SUPPORTS 05
05 50 00.N2 FITNESS AREA WIRE MESH 05
05 50 00.N3 FITNESS AREA ROOF SYSTEM 05
05 50 00.N4 FITNESS AREA STORAGE SHELVING 05
05 50 00.P1 GALVANIZED STEEL VENT GRILLE W/ FIRE SMOKE DAMPER 05
05 50 00.Q1 PAINTED STEEL SCREEN FENCING 05
05 50 00.R1 TILT UP GATE PANEL 05
05 50 00.S1 PLANTER TRAYS 05
05 50 00.S2 ALUMINUM CLADDING 05
05 50 00.S3 PLANTER / GUARDRAIL UNIT 05
05 51 00.A1 PT GALV STEEL STRINGER 05
05 51 00.A2 PT STEEL STRINGER 05
05 51 00.A3 GALV STEEL STRINGER 05
05 51 00.A4 STEEL STRINGER GREY PRIMED 05
05 51 00.B1 PT GALV STEEL PAN TREAD 05
05 51 00.B11 PT STEEL CHECKER PLATE TREAD 05
05 51 00.B2 PT STEEL PAN TREAD 05
05 51 00.B20 PRECAST CONC ON BENT STEEL TREAD 05
05 51 00.B3 PT GALV STEEL CHECKER PLATE TREAD 05
05 51 00.B7 GALV STEEL GRATING TREAD 05
