Relay
Dual Temperature
Sprint The Relay is our unique dual temp swimspa with a ‘see through’ divider. The spa and swimming Relay Standard Features
• 5440 x 2280 x 1370
sections are separated meaning you can have 2 different temperatures set, simultaneously in the
same swimspa, a warm relaxing spa end with a cooler more practical swimming end. The spa end • LED Controls
has seating for 5 and is separated from the swimming end by a transparent dividing wall. The Relay Dual Temperature • 2 LED Underwater Lights
• 2 Piece Deluxe Safety/Insulation Cover
comes as standard with our Catalina exercise equipment, 8 LED crystal fountains and 2 LED cascade • Bluetooth™ Audio with Speakers and Subwoofer
waterfalls, an LED underwater lighting system as well as LED jets and controls. The Relay is available in • 2 x 2.5hp (1.9kW) 2 Speed Pumps • Thermo - Pane Insulation with Radiant Guard
both above and in ground styles. • 3 x 3hp (2.2kW) Boost Pumps • Exercise Equipment
• 2 x 3kW Heaters • Chemical Starter Kit
• 3 River Swim Jets • Water Capacity – 8800 ltrs
• Auxiliary Control Panel • Dry Weight – 1600 kg
• From 70 Amp Supply (30+40) Spa
• 2 x Ozone
• 2 x 100sq ft Filtration • Seats 5
• 42 Stainless Hydrotherapy Jets
Optional Upgrades • Heated Air Blower
• Pro Swim • Fixed See Through Divider
• *Balboa™ Wi-Fi Upgrade • 2 LED Crystal Water Features
• Auxiliary Heater Controller (installed) • LED Stainless Jets
• Titanium LPHW Heat Exchanger, Pool
inc AHC (installed) • 3 River Swim Jets
• 3kW Slave Heater • 8 LED Underwater Side Lights
• 6 LED Crystal Water Features
• 2 LED Cascading Waterfalls
• 6 LED Step Lights
• Waterline and Swim Lane Tile
• 2 Stainless Exercise Rails
A beautiful installation of a Relay inside a
purpose built swimspa room. In-ground available see page 19 for more information
Inset detail of the Relay’s unique, clear divider
*On dual temperature models only available on either pool or spa
