Coaxial Cable Slitting & Shaving Tools

Messengered Web & Drop Cable Slitters

MWS Series

Messengered Web Slitter
• Ideal cable messenger web slitting tool for applications such as pole clamping or dead-end attachment
• No adjustment necessary on the factory-set blade

MWS Series Ordering Guide
TIMES
COMMSCOPE® QR COMMSCOPE® P3 TIMES FIBER T10 FIBER TX REPLACEMENT BLADE
MODEL PART # LENGTH WEIGHT
320 500 540 715 412 500 565 625 700 750 412 500 625 750 565 700 MODEL PART #
JCAM JCAM JCAM JCAM JCAM JCAM MS MS MS MS MS MS
MWS 400 37049 ∙ ∙ ∙
MWS 500 37037 ∙ ∙ ∙ ∙ ∙ CB 209 36343 3.8″ (96 mm) 6.7 oz (191 g)
MWS 700 37030 ∙ ∙ ∙ ∙ ∙ ∙

MWSS Series

Messengered Web Slitter & Shaver Tool
• Ideal combination tool effectively slits messengered web & shaves the residual web material from the
cable jacket for proper cable preparation
• Spring-loaded blade shield design secures the blade to the tray & ensures safety during use
• Shaving blade can be field-adjusted while the slitting blade is fixed & factory-set
• U.S. Patent No. 6,427,331

MWSS Series Ordering Guide
TIMES
COMMSCOPE® QR COMMSCOPE® P3 TIMES FIBER T10 FIBER TX REPLACEMENT BLADES
MODEL PART # LENGTH WEIGHT
412
700
750
625
500
565
320 500 540 715 JCAM JCAM JCAM JCAM JCAM JCAM 412 500 625 750 565 700 SHAVING PART # SLITTING PART #
MS
MS
MS
MS
MS
MS
MWSS 400 37045 ∙ ∙ ∙ CB 229 37048
3.8″ 6.7 oz
MWSS 500 37033 ∙ ∙ ∙ ∙ ∙ ∙ CB 227 37036 CB 209 36343
(96 mm) (191 g)
MWSS 700 37023 ∙ ∙ ∙ ∙ ∙ ∙ ∙ CB 226 37027
DCS Series
Coax Drop Cable Slitter
• Lightweight & compact cable slitter designed to slit the web on 59/6, 7 & 11 series messengered coaxial &
dual coaxial drop cables, as well as shave the residual web material from the cable jacket
• High-visibility red body is equipped with built-in saddle & spring-loaded jaws to easily position the cable,
as well as a shaving blade to remove residual ridge material for quick connectorization
• U.S. Patent No. 6,131,289
DCS Series Ordering Guide

REPLACEMENT BLADES
MODEL PART # CABLE COMPATIBILITY JACKET COMPATIBILITY LENGTH WEIGHT
SLITTING MODEL PART # SHAVING MODEL PART #
DCS 36340 59/6, 7 & 11 Messengered / Dual Cables PVC / Polyethylene CB 209 36343 CB 283 36349 2.75″ (70 mm) 5 oz (140 g)
