03 AUTOMATION & CONTROL
TIME RELAY
AH3 CH3 DH48S-S H3Y-2 TSDT-N
TIME RELAY
Part No Description Price
AH3-1 Variable, SPDT 17.00
AH3-2 Variable, DPDT 24.50
CH3-A Multi Range Variable, DPDT 30.00
H3Y-2 SPDT (2C) 31.00
DH48S-S Repeat Cycle, SPDT 45.00
TSDT-N Star Delta Timer 45.00
Rated Voltage: VAC: 12-24-110-220-380 / VDC: 12-24 / VAC/ DC12 - 240
Time Range: Sec: 1, 3, 6, 10, 12, 30, 60 / Min: 3, 6, 10, 12, 30, 60
FLOATLESS RELAY
AFR-1
C6IF-GP
FLOATLESS RELAY
Part No Description Voltage Price
AFR-1 Action Indication 240VAC 27.00
C6IF-GP Action Indication 240VAC 29.00
