Electrical Performance (STC : AM 1.5, 1000W/m², 25˚C)

Module Type ST144HM410STP
Maximum Power (Pmax / W) 410
Power Tolerance ±5%
Maximum Power Voltage (Vm / V) 41.7
Maximum Power Current ( Im / A) 9.84
Open Circuit Voltage (Voc / V) 51.2
Short Circuit Current ( Isc / A) 10.29
Module Efficiency (%) 20.2
Mechanical Properties Operation Conditions

Dimensions (L×W×H / mm) 2024 x 1004 x 35mm Maximum System Voltage (VDC) 1500 (IEC) / 1500 (UL)
Weight 22.8 kg Maximum Series Fuse Rating (A) 20
Solar Cells Monocrystalline 158.75 x 79.375mm Operating Module Temperature ( ˚C ) -40 to +85
No. of Cells 144 (6×24)
Glass 3.2mm High Transmission, Temperature Properties
AR Coated Heat Strengthened Glass Normal Operating Cell Temperature 41±3 ˚C
Frame 33mm Anodized alumunium alloy Temperature Coefficient of Pm -0.36 %/ ˚C
Junction box IP68 3 Diodes, Triple pole type Temperature Coefficient of Voc -0.26 %/ ˚C
Cables 2*4mm² , L=1400mm Temperature Coefficient of Isc +0.04 %/ ˚C

Connectors IP67, MC4 compatible
System Design Packing Configuration
Hail safety impact velocity - Container Sizes - -
Static Load (Front/Back) - Pieces per pallet - -
Application class - Pallets per Container - -
Fire safety class (IEC61730) - Total pieces - -

I II III 35±1
Made in Indonesia ST144HM410mmyy0001
200 4*Ø9-14 I-V Curves at different irradiances, Temp.cell 25℃
314±1 1 14 12 1000W/m²
4*Ø9-14 V 12.5
10
959±1
800W/m²
Current (A) 600W/m²
DETAIL - V 8
VI 35±1 6
4*Ø7-20
400W/m²
962±1 4
4*Ø7-10
2024±1 1300±1 400±1 2023.5±1 14 2 200W/m²
IV 257.6 2
0
0 10 20 30 40 50 60
DETAIL - VI
Voltage (V)
450±1 35
35±1
A A I-V Curves at different cell temperatures, AM1.5, 1000W/m²
12
6*Ø4.5
6*Ø4.5 VII 10 18
362±1 10 25℃
180 35 8 50℃
1004±1 35±1 Current (A)
BACK VIEW 75℃
FRONT VIEW SIDE VIEW DETAIL - VII 6
3 +2 -0 18.25 4
11.5±0.2
6.4 2
30 30
ST144HM410mmyy0001
2 +2 -0 15
Made in Indonesia 35±0.2 9.1 1.2
0
1.8±0.2
0 10 20 30 40 50 60
Voltage (V)
35±0.2
18.25 18.25 FRAME PROFIL A-A
DETAIL - I DETAIL - II DETAIL - III DETAIL - IV
