MACHUELO METRICOS EN ACERO, HY-PRO
IP Medida Largo Total Largo Corte Diámetro Zco. Cuadra
2990401 M3 x 0.50 1-15 / 16 " 5/8 " 0.141 " 0.110 "
2990601 M4 x 0.70 2-1 / 8 " 3/4 " 0.168 " 0.131 "
18 2990801 M5 x 0.80 2-3 / 8 " 7/8 " 0.194 " 0.152 "
2991001 M6 x 1.00 2-1 / 2 " 1 " 0.255 " 0.191 "
2991301 M8 x 1.00 2-23 / 32 " 1-1 / 8 " 0.318 " 0.238 "
2991401 M8 x 1.25 2-23 / 32 " 1-1 / 8 " 0.318 " 0.238 "
2991801 M10 x 1.50 2-15 / 16 " 1-1 / 4 " 0.381 " 0.286 "
2992201 M12 x 1.50 3-3 / 8 " 1-21 / 32 " 0.367 " 0.275 "

JUEGO DE INSERTOS PARA HELICOIL CON MACHUELO
FRACCIONAL UNF
IP Medida Largo Total Largo Corte
V-04123 10--32 5.1 20
V-04125 1/4X28 6.7 20
V-04126 5/16X24 8.3 20
V-04127 3/8X24 9.8 15
V-04129 1/2X20 13 10

Machuelos hy-pro | Insertos Helicoil

JUEGO DE INSERTOS PARA HELICOIL CON MACHUELO JUEGO DE INSERTOS PARA HELICOIL METRICOS
FRACCIONAL UNC IP Medida Largo Total Largo Corte
IP Medida Largo Total Largo Corte V-04005 M3 X 0.5 3.2 20
V-04102 6 X32 3.8 20 V-04007 M4 X 0.7 4.2 20
V-04103 8 X 32 4.4 20 V-04009 M5 X 0.8 5.2 20
V-04104 10 X24 5.2 20 V-04010 M6 X 1.0 6.3 20
V-04107 1/4 X20 6.7 20 V-04012 M8 X 1.25 8.3 20
V-04108 5/16 X 18 8.3 20 V-04016 M10 X 1.5 10.4 15
V-04109 3/8 X16 9.9 15 V-04021 M12 X 1.75 12.4 10
V-04111 1/2 X 13 13 10 5 (8.40), 5 (12.40),
V-04096 M14X1.25 14.4
V-04113 5/8--11 16.5 10 5 (16.40)
V-04114 3/4--10 19.75 5 V-04028 M14 X 2.00 14.5 10

V-04032 M16 X 2.00 16.5 10
V-04035 M18 X 2.00 18.5 5

………………………………………………………………………………………………………………………………………………………..............................
