Page 106 - TCD Catalog 2017
P. 106
TCD Parts Inc.
Plastic Compression Fittings
plastic fittings available in four types of material COMPRESSION
MALE CONNECTOR
N= White Nylon made from virgin grade formulated to
resist physical stress and abrasion. Meets FDA requirements.
B= Black Polyethylene made from a high molecular Part # Description
weight linear polyethylene. Formulated for chemical 30-M1022K 1/4" COMP X 1/8" MPT CONNECTOR; KYNAR
30-M1022N 1/8" COMP X 1/8" MPT CONNECTOR; NYLON
compatibility and high impact resistance at lower temps.
30-M1022P 1/8" COMP X 1/8" MPT CONNECTOR; POLYPROPYLENE
Polyethylene is NSF approved for potable water.
30-M1042K 1/4" COMP X 1/8" MPT CONNECTOR; KYNAR
P= Polypropylene made form the finest polypropylene 30-M1042N 1/4" COMP X 1/8" MPT CONNECTOR; NYLON
resins. Used for its resistance to a wide range of chemicals. 30-M1042P 1/4" COMP X 1/8" MPT CONNECTOR; POLYPROPYLENE
Working pressures decrease as temperatures increase. 30-M1044K 1/4" COMP X 1/4" MPT CONNECTOR; KYNAR
30-M1044P 1/4" COMP X 1/4" MPT CONNECTOR; POLYPROPYLENE
K= Kynar a polyvinylidene fluoride, has outstanding
30-M1046N 1/4" COMP X 3/8" MPT CONNECTOR; NYLON
chemical resistance for handling highly corrosive fluids. FDA
30-M1062N 3/8" COMP X 1/8" MPT CONNECTOR; NYLON
listed, NSF listed.
30-M1064P 3/8" COMP X 1/4" MPT CONNECTOR; POLYPROPYLENE
30-M1066P 3/8" COMP X 3/8" MPT CONNECTOR; POLYPROPYLENE
COMPRESSION 30-M1068P 3/8" COMP X 1/2" MPT CONNECTOR; POLYPROPYLENE
FEMALE ELBOW 30-M1082N 1/2" COMP X 1/4" MPT CONNECTOR; NYLON
30-M1084P 1/2" COMP X 3/8" MPT CONNECTOR; POLYPROPYLENE
30-M1086P 1/2" COMP X 1/2" MPT CONNECTOR; POLYPROPYLENE
Part # Description COMPRESSION MALE CONNECTOR
30-F2042K 1/4" FPT X 1/8" COMP KYNAR WITH SS GRIPPER
30-F2042P 1/4" FPT X 1/8" COMP POLYPROPYLENE
30-F2044K 1/4" FPT X 1/4" COMP KYNAR
30-F2044P 1/4" FPT X 1/4" COMP POLYPROPYLENE
30-F2064P 1/4" FPT X 3/8" COMP POLYPROPYLENE Part # Description
30-F2084P 3/8" FPT X 1/2" COMP POLYPROPYLENE 30-M1044SP 1/4" COMP 1/4" MPT CONNECTOR FOR COPPER OR
OTHER HARD TUBING, SS GRIPPER
30-F2086P 1/2" FPT X 3/8" COMP POLYPROPYLENE
COMPRESSION FEMALE
COMPRESSION CONNECTOR
UNION TEE
Part # Description
30-F1042K 1/8" FPT X 1/4" COMPRESSION; KYNAR
Part # Description 30-F1042P 1/8" FPT X 1/4" COMPRESSION; POLYPROPYLENE
30-3022N 1/8" X 1/8" X 1/8" COMP NYLON 30-F1044K 1/4" FPT X 1/4" COMPRESSION; KYNAR
30-3044N 1/4" X 1/4" X 1/4" COMP NYLON 30-F1044P 1/4" FPT X 1/4" COMPRESSION; POLYPROPYLENE
30-3044P 1/4" X 1/4" X 1/4" COMP POLYPROPYLENE 30-F1144K 1/4" FPT X 1/8" COMPRESSION; KYNAR
30-3066P 3/8" X 3/8" X 3/8" COMP POLYPROPYLENE 30-F1144P 1/4" FPT X 1/8" COMPRESSION; POLYPROPYLENE
30-3078P 1/2" X 1/2" X 1/2" COMP POLYPROPYLENE 30-F2086P 1/2" FPT X 3/8" COMPRESSION; POLYPROPYLENE
