Control of Industrial Major Accident Hazards (CIMAH) Report Page 49
Ranhill SAJ Sdn. Bhd. Revision 01
Part D: Information on the Potential Major Accident Date Aug 2019

Consequence
Hazardous Concentration
Major Accident Scenario Location Maximum Affected Area
Substances (ppm)
Distance (m)
Chlorine Room
Administration Office
495
(50% fatality) 214.53 Guard House
Staff quarters
Rattan Factory
Chlorine Room
4827 Chemical Building
(100% fatality) 32.11 Administration Office
Guard House
Onsite
Staff quarters
10 612.68 Taman Kekwa
(IDLH) Teck Seng Food Industries
Rattan Factory
Chlorine Drum 10mm Hole Chlorine KT2 Chlorine Kampung Padang Lalang
Diameter Leak (Door Opened) Room Chlorine Room
495 Chemical Building
(50% fatality) 32.26 Administration Office
Guard House
4827 Chlorine Room
(100% fatality) 4.81 Chemical Building

Table D.6.1.4: Consequence to the Surrounding Likely to be affected by Major Accident
