CONSTRUCT

C3.5 Laminate Wall Panels

Skirting to the dining area will be finished SKIRTING SECTION DETAIL
in 100mm high, 6mm compact laminate in
Natural integrity and 135mm high, 6mm thick For stall risers lower than 300mm high then the
compact laminate in all other interior concepts. compact laminate ‘skirting’ should be used up
The laminate must be packed out via 6mm to the window sill. This will avoid small laminate
WBP plywood, fitted between the laminate panels between the usual skirting line and the
and existing wall surface. Alternatively (and u/s of the window sill.
at no additional cost to McDonald’s), 12mm
compact laminate may be used in this location
to avoid the requirement for packing. The WBP
ply packing should be stopped 15mm short of
the floor finish to avoid any potential capillary
action by water.

C3.5 Laminate Wall Panels 3.0 23 June 2016
