CABINET HARDWARE & LOCKS

OVAL SLAM LATCH

Stainless Steel 316

● Concealed handle hinge design for modern style.
● Adjustable slide ensures rattle free operation.
● Reversible backing plate for wide range 0107885
of door thickness. C
D
● Installation screws are included. 0107887 INSTALLATION HOLE DOOR
● Screw size #6. A B
DOOR THICKNESS
Bulk No. Model A mm B mm C mm D mm BACKING PLATE
0107885 W/O Lock 8~22(5/16"~7/8") 19~25(3/4"~1") 62(2-7/16") 51(2") ADJUSTABLE SLIDE FRAME
8~22(5/16"~7/8")
0107887 W/ Lock 19~25(3/4"~1") 62(2-7/16") 51(2")
SLAM LATCH

Stainless Steel 316

● Smooth inside. Designed for light
and medium weight doors.
● Comes with a 3mm spacer ring.
9507774
● 6mm and 10mm spacer rings are
available upon request.
● Installation screws are included. 9507775 C
● Screw size #8. INSTALLATION HOLE DOOR
D
A B
THICKNESS
DOOR
Bulk No. Model A mm B mm C mm D mm BACKING PLATE
9507774 W/O Lock 12~22(1/2"~7/8") 25(1") 61(2-3/8") 51(2") FRAME
9507775 W/ Lock 12~22(1/2"~7/8") 25(1") 61(2-3/8") 51(2")

WATERPROOF SLAM LATCH
Stainless Steel 316

● Designed for waterproof compartment.
● Using for exterior deck lockers and live bait well.
● Comes with a 3mm spacer ring.
9221520
● 6mm and 9mm spacer rings are available upon request.
● Max. door thickness is 22mm by using longer screws. 9221525
● Screw size #8.

C
INSTALLATION HOLE
Bulk No. Model Housing A mm B mm C mm D mm D
DOOR
9221520 W/O Lock S.S.316 10~13(3/8"~1/2") 25(1") 61(2-3/8") 51(2") A
9221521 W/ Lock S.S.316 10~13(3/8"~1/2") 25(1") 61(2-3/8") 51(2") DOOR B
9221524 W/O Lock Nylon 10~13(3/8"~1/2") 25(1") 61(2-3/8") 51(2") THICKNESS
BACKING PLATE FRAME
9221525 W/ Lock Nylon 10~13(3/8"~1/2") 25(1") 61(2-3/8") 51(2")
