PRODUCTION AUTOMATION

So, for example, the table of the results of of the computer on which the calculation
calculating the transmission according to is made. The duration of the operator’s
figs. 1 and 2, the processing of the wheel of work in calculating the transmission (if
which is performed by gear cutting, takes the calculation is not performed many
14 pages of A4 format. The calculation times in order to optimize any geometric
numbers indicated by the program are parameters) does not exceed five minutes.
the current ones that it remembers in the
service file.
When calculating the number 9999,
the next calculation is assigned the number
1. The date and time of the calculation are
read by the program from the date and time

Table of parameters of the gear ring of gear wheel. Table of the gears of the wheel.
Calculation serial number: 1139. Calculation serial number: 1139.
Date: 04/10/2016; Time 20 hours. 22 minutes Date: 04/10/2016; Time 20 hours. 22 minutes

Module m 5.000 Module m 5.000
Teeth number z 74 Teeth number z 85
Dip angle 15˚12 ‘ 10’’ Dip angle 15˚12 ‘ 10’’
Tooth line direc- - right Tooth line direc- - right
tion tion
Normal rack - GOST 13755-81 Normal rack - GOST 13755-81
tooth profile tooth profile
Head h*g .200 Offset coefficient x 0.600
modification
height factor Precision ac- - 7-6-7-Вс/III -146
Head .010 cording to GOST
modification 1643-81
depth factor Ball front size M +0.791
Offset coefficient x 0.600
Precision ac- - 7-6-7-Вс/III -146 436.630
cording to GOST +0.544
1643-81 Ball diameter D 7.938
chord thickness Sy -0.160 Pitch diameter d 440.413

7.625 Fig. 2.

-0.260
Chord height hay 4.636
Pitch diameter d 383.418
Fig. 1.
