PROFILE GUIDE CUTTERS
145
TCT PROFILE GUIDE 90o WITH BEARING
The profile guide cutters (PGC) range are made with plunging centre points ideal
for blind proofing and plunging (ie double skinned plywood). The PGC range have
bearing guides which are designed to run off a top mounted template. AND TOOLING MACHINES

> generally in stock for a two day delivery
> orders must be placed by 4.00pm

CODE D MM L MM OL MM OL MM 1 /4" 1 /2"
PGC9525 9.5 25 72 − £31.98 −
PGC12795 12.7 9.5 57 − £29.61 −
PGC12719 12.7 19 66 − £31.98 −
PGC127 12.7 25 72 − £33.17 −
PGC127114 12.7 32 79 − £34.35 −
PGC16 16 20 66 − £35.54 −
PGC16LK 16 25 71 − £43.83 −
PGC19 19 50 − 105 − £58.04
PGC1963 19 63 − 117 − £72.25

OVOLO AND ROUNDING | OVER CUTTERS

ROUNDING OVER BEARING GUIDED TCT
Available in fractional sizes to relieve corners on small panels, or larger radi for tools
stair mosings, window boards and many shelf and display units. Careful feeding
will prevent the pin form marking work piece. TCT pin diameter 8.9mm.

> generally in stock for a two day delivery
> orders must be placed by 4.00pm

CODE D MM R MM L MM OL MM 1 /4" 1 /2"
ROCB1 18 1 7 51 £37.90 £37.90
ROCB1.6 19.2 1.6 8 51 £37.90 £37.90
ROCB2 20 2 10 51 £37.90 £37.90
ROCB3 22 3 10 51 £50.40 £45.01
ROCB4 24 4 10 52 £45.01 £45.01
ROCB48 26 4.8 11 53 £45.01 £45.01
ROCB5 25.6 5 11 53 £45.01 £45.01
ROCB6 26 6 12 54 £53.30 £53.30
ROCB63 28 6.3 13 55 £47.38 £47.38
ROCB516 28 8 15 57 £47.56 £47.56
ROCB95 35 9.5 15 59 £48.56 £48.56
ROCB11 38 11 18 59 £55.67 £55.67
ROCB127 41 12.7 19 59 £56.86 £56.86

make it once... make it Mighton www.mightonproducts.com 0800 056 0471
