TRIMMERS
147
TCT 90o INTERNAL BEARING GUIDE EDGE TRIMMER | SMALL DIAMETERS
The profile guide cutters (PGC) range are made with plunging centre points ideal
for blind proofing and plunging (ie double skinned plywood). The PGC range have
bearing guides which are designed to run off a top mounted template. AND TOOLING MACHINES

> generally in stock for a two day delivery
> orders must be placed by 4.00pm

CODE D MM L MM OL MM OL MM 1 /4" 1 /2"
IBGT63 6.3 12.7 59 − £21.32 −
IBGT63LK 6.3 25 71 − £22.51 −
IBGT38 9.5 12.7 59 − £23.69 −
IBGT38LK 9.5 25 72 80 £23.69 £28.43
IBGT90 12.7 16 58 71 £26.06 £30.80
IBGT90LK 12.7 25 68 80 £22.51 £26.06
IBGT90LK1 12.7 38 85 93 − £54.49
IBGT90LK2 12.7 50.8 − 106 − £66.33
BGT90 18 12 58 − £29.61 −
BGT90S 18 12 58 − £34.35 −
BGT90LKS 18 25 69 79 £40.27 £40.27
BGT90LK1 18 38 81 91 − £56.86
BGT90LK2 18 50 − 104 − £67.52

GROOVING AND ENGRAVING

TCT ‘V’ GROOVING | LARGE SECTION tooling

Can be used for chamfering or deep groove work. C refers to bevel.
Do not re-sharpen on the front face, lightly regrind the cutter back relief
only. Recommended for CNC controlled feed to avoid point breakage.

> generally in stock for a two day delivery
> orders must be placed by 4.00pm

CODE D MM L MM L1 MM D MM C MM IA OL MM 1 /4" 1 /2"
VGC45 18 9 4 1 12 90 46/56 £27.24 £27.24
VGC45L 30 14 4 1 19 90 52/62 £55.67 £55.67
VGC45LK 38 19 6 1 25 90 67 − £58.04
VGC45EL 51 25.5 9.5 1 35 90 74 − £103.05

make it once... make it Mighton www.mightonproducts.com 0800 056 0471
