SECURITY SEALS
® CLASS H S, & I STEEL CABLE TYPE
ALL SEALS MEET ISO 17712:2010

FIXED LOCK CABLE SEAL
• HIGH STRENGTH, GALVANIZED, FLEXIBLE CABLE.
• SERIAL NUMBERS PRINTED ON HEX BODY. H-Classed are
• MANY POSSIBLE VARIATIONS TO SECURE DOOR RODS & LATCHES. C-TPAT and ISO/DIS 17712
• CORROSION RESISTANT POLY COATED METAL LOCK BODY. Compliant
CABLE
DIAMETER Ø
9/16" Buffers USA Buffers USA
012345
012345
13.5 MM
1 1/16"
27 MM 1 1/2" CABLE 1 1/4"
38 MM LENGTH 31 MM
BODY CABLE CABLE MIN. PULL APART WEIGHT PCS/
MODEL CLASS MATERIAL DIAMETER Ø LENGTH STRENGTH PER PC BOX
3202-2154 S METAL 3/16" 12" 680 LBS 0.07 LBS 250
4.8 MM 305 MM 310 Kg 0.03 Kg
3202-2944 S METAL 3/16" 16" 680 LBS 0.18 LBS 250
4.8 MM 406 MM 310 Kg 0.08 Kg
3202-2945 I METAL 1/16" 48" 240 LBS 0.06 LBS 300
1.8 MM 1,219 MM 110 Kg 0.03 Kg

PULL TIGHT FIXED LOCK CABLE SEAL
• HEAVY DUTY SELF-LOCKING DESIGN WITH FLEXIBLE CABLE.
• SLIDING LOCK ELIMINATES ANY SLACK BETWEEN LOCKING POINTS.
• DOES NOT FORM A LOOP, DESIGNED TO LOCK TWO OR MORE LATCHES. C-TPAT and ISO/DIS 17712
Compliant
• SERIAL NUMBER PRINTED ON PUSH ON LOCK BODY.
CABLE
DIAMETER Ø
1 1/4"
32 MM
Ø1 1/16" 1 7/8" CABLE 1 7/16"
27 MM 47.5 MM LENGTH 37 MM

BODY CABLE CABLE MIN. PULL APART WEIGHT PCS/
MODEL CLASS MATERIAL DIAMETER Ø LENGTH STRENGTH PER PC BOX
3202-2946 H METAL 1/4" 45" 4,400 LBS 0.75 LBS 50
6.4 MM 1,143 MM 2,000 Kg 0.34 Kg

®
