Page 26 - Envision E-Catalog

DOWNLIGHT 4INCH

The EnVision retrofit reflector downlight
surpasses most other recessed lights on the

market. It has an aluminum heatsink for
efficient heat dissipation, and a state of the art
LED driver which gives it excellent dimming

performance. At 750 Lumens, and fully
dimmable, you have plenty of light when

desired. The light turns on instantly, and is not
affected by frequent on/off switching.

Applications:

• Recessed Downlighting
• New Construction

• Commercial Lighting

Product Information:
4 inch (can)
• Increase energy savings and shorten payback period
• High intensity: ready to replace existing 75w halogens

• Title 24 (Ideal) Connector Plug

• Dimmable: Compatible with most dimmers down to 5%
3.7 inch
• Fits most 4inch cans

Includes
E26 Converter
Beam
Type Model Volt Watt Lumen Color CRI Spread

4INCH LED-SQ-RES-4-11W-WW 120V 11W 750 Warm-3000k >83 120°

4INCH LED-SQ-RES-4-11W-DL 120V 11W 750 Day- 5000k >83 120°

EnVision LED Lighting, Inc.
801 E Washington Blvd. | Los Angeles, CA 90021 | P: 213-741-1550 | www.envisionledlighting.com
24
