Page 69 - GDTNZ18_Product_Catalogue_2.1_Print_Ready_Neat

Eagle F1 Asymmetric 2 SUV

ASYMMETRIC
100% ON-ROAD

All the benefits of an ultra high-performance tyre, optimised for high-end SUVs. Maximised
grip and tracking ensures an enjoyable drive.

Braking Wet Handling
Performance Performance Performance

FEATURES BENEFITS
Active CornerGrip Technology Enhanced control around corners
Open asymmetric tread design Wet handling and aquaplaning resistance
Refined tread design Delivering a smooth, quiet ride

TYRE SIZE SERVICE SECTION WIDTH OVERALL STATIC REVS PER SINGLE MAX APPROVED RIM OE
DESIGNATION DESCRIPTION (MM) ON DESIGN DIAMETER LOADED KILOMETRE LOAD (KG) AT MAX WIDTH (INCHES) FITMENTS
RIM (MM) RADIUS PRESSURE (PSI)
(MM) 4WD/RV/SUV
235/55R19 101Y 245 on 7 1/2 741 337 445 825 @ 36 6 1/2 - 8 1/2 Porsche Macan
255/55R19 111Y 265 on 8 763 347 432 1090 @ 42 7 - 9 Audi Q7
265/45R20 108Y 266 on 9 746 339 442 1000 @ 42 8 1/2 - 10 Maserati Levante
285/45R20 112Y 285 on 9 1/2 764 348 432 1120 @ 42 9 - 10 1/2 Audi Q7, SQ7
HIGHWAY TERRAIN
285/40R21 109Y 290 on 10 761 346 433 1030 @ 42 9 1/2 - 11 Audi Q7, SQ7

Eagle F1 Asymmetric 3 SUV

ASYMMETRIC
100% ON-ROAD
Thanks to ActiveBraking Technology, contact with the road is increased when braking,
resulting in a shorter distance in both wet and dry conditions. Additionally, the tyre is made
with a unique Grip Booster compound that increases the tyre’s stickiness with the road
surface.

Grip Braking Handling
Performance Performance Performance

FEATURES BENEFITS
ActiveBraking Technology Shorter stopping distance in both wet and dry
Grip Booster compound Powerful grip

Optimised SUV construction Improved handling, stability and tread wear

TYRE SIZE SERVICE SECTION WIDTH OVERALL STATIC REVS PER SINGLE MAX APPROVED RIM OE
DESIGNATION DESCRIPTION (MM) ON DESIGN DIAMETER LOADED KILOMETRE LOAD (KG) AT MAX WIDTH (INCHES) FITMENTS
RIM (MM) RADIUS PRESSURE (PSI)
(MM)
235/55R19 101Y 245 on 7 1/2 741 337 445 825 @ 36 6 1/2 - 8 1/2 Alfa Romeo Stelvio
245/45R21 104W 243 on 8 753 342 438 900 @ 42 7 1/2 - 9 Jaguar E-Pace
245/45R21 104Y 243 on 8 753 342 438 900 @ 42 7 1/2 - 9 Jaguar E-Pace

68
