2020 DRAG RACING

MM, MB, MW, & MG Series General Purpose-Precision 3-Piece Rod Ends
General purpose three-piece rod ends are assembled using a protective-coated carbon steel body and race, and a heat-treated, hard chrome-plated alloy steel ball.
Bore x Thread Male Part No. Ult. Radial Female Part No. Ult. Radial
Size Reference RH LH Static Load RH LH Static Load
3/16" x 10-32 AURMM-3 AURMB-3 1,169 lbs. — — —
1/4" x 1/4"-28 — AURMB-4 2,158 lbs. — — —
5/16" x 5/16"-24 AURMM-5 AURMB-5 2,784 lbs. AURMW-5 — 3,133 lbs.
3/8" x 3/8"-24 AURMM-6 AURMB-6 4,218 lbs. — — —
7/16" x 7/16"-20 — — — AURMW-7 — 4,218 lbs.
1/2" x 1/2"-20 AURMM-8 AURMB-8 6,660 lbs. AURMW-8 — 6,660 lbs.
5/8" x 5/8"-18 AURMM-10 AURMB-10 7,364 lbs. — — —
3/4" x 3/4"-16 AURMM-12 AURMB-12 11,518 lbs. AURMW-12 — 11,518 lbs.
AM, AB, AW & AG Series High Strength 3-Piece Rod Ends
High-strength, three-piece rod ends feature heat-treated, alloy steel bodies with heat-treated and protective alloy steel races and heat-treated, hard chrome-
plated alloy steel balls.
Bore x Thread Male Part No. Ult. Radial Female Part No. Ult. Radial
Size Reference RH LH Static Load RH LH Static Load
1/4" x 1/4"-28 AURAM-4 AURAB-4 5,260 lbs. — — —
5/16" x 5/16"-24 AURAM-5 AURAB-5 7,639 lbs. AURAW-5 — 7,639 lbs.
3/8" x 3/8"-24 AURAM-6 AURAB-6 9,544 lbs. AURAW-6 — 9,544 lbs.
7/16" x 7/16"-20 AURAM-7* AURAB-7* 10,285 lbs. AURAW-7 — 10,285 lbs.
1/2" x 1/2"-20 AURAM-8* AURAB-8* 16,238 lbs. AURAW-8 — 16,238 lbs.
5/8" x 5/8"-18 AURAM-10* AURAB-10* 17,955 lbs. AURAW-10 — 17,955 lbs.
3/4" x 3/4"-16 AURAM-12* AURAB-12* 28,081 lbs. AURAW-12 — 28,081 lbs.
*Also stocked with PTFE liner by adding “T” to end of part number.

XM & XB Series Extra Strength Male 3-Piece Rod Ends High Misalignment Series Male Rod End And
Extra-strength, three-piece rod ends are manufactured using Spherical Bearings NEW!
a protective-coated carbon steel body, heat-treated alloy steel Engineered specifically for high misalignment, threaded rod
race and heat-treated, hard chrome-plated alloy steel ball. ends and spherical bearings are constructed using heat-treated
Bore x Thread Male Part No. Ult. Radial 4340 steel bodies, heat-treated 4130 steel races, heat-treated,
Size Reference RH LH Static Load hard chrome-plated alloy steel balls, and PTFE liners.
1/2" x 1/2"-20 AURXM-8 AURXB-8 12,807 lbs. Part No. Description
5/8" x 5/8"-18 AURXM-10 AURXB-10 16,565 lbs.
AURHXAM-7T 7/16" Bore x 1/2"-20 Thread Rod End
XAM & XAB Series High Strength AURHAB-8T .500" I.D. x 1.125" O.D. Spherical Bearing
Male 3-Piece Rod Ends AURHAB-10T .625" I.D. x 1.375" O.D. Spherical Bearing
AURHAB-12T .750" I.D. x 1.562" O.D. Spherical Bearing AURHXAM-7T
Three-piece, high-strength rod ends are constructed
with heat-treated alloy steel bodies, heat-treated alloy Mono-Ball Shock Bearings
steel races, and heat-treated, hard chrome-plated alloy steel balls. Part No. Description
AURCOM-8T-24 Replacement 1/2" Dia. Bearing For Bilstein Shocks
Bore x Thread Male Part No. Ult. Radial
Size Reference RH LH Static Load AURCOM-8T-31 Replacement 1/2" Dia. Bearing For Ohlins/Koni Shocks
3/8" x 7/16"-20 — AURXAB-6T † 17,508 lbs. Mono Ball Bearings
7/16" x 1/2"-20 AURXAM-7T † — 23,452 lbs.
1/2" x 5/8"-18 AURXAM-8 AURXAB-8* 31,390 lbs. Race is carbon steel with protective coating. Ball is hardened
1/2" x 3/4"-16 AURXAM-8T-2 † AURXAB-8T-2 † — steel, heat-treated, and hard chrome-plated.
5/8" x 3/4"-16 AURXAM-10* AURXAB-10 40,572 lbs
*Also stocked with PTFE liner by adding “T” to end of part number. Part No. I.D. O.D.
†Include a PTFE liner. AURCOM-8 .500" 1.000"
AURCOM-10 .625" 1.1875"
PRM & PRB Performance Racing Series 3-Piece AURCOM-12 .750" 1.4375"
Male Rod Ends AURCOM-12T* .750" 1.4375"
NEW!
Performance Racing Series three-piece *Mono ball that includes a PTFE liner.
rod ends are manufactured using heat-treated, 4340 Rod Ends With Studs
steel bodies, stainless steel heat-treated races, heat- Perfect for throttle linkage and other applications.
treated, hard chrome-plated alloy steel balls. Each rod end also includes a
Size Male Female
permanently bonded PTFE liner for reduced friction and improved durability. 1/4" RH AURCM-4S AURCW-4S
Bore x Thread Male Part No. Ult. Radial 5/16" RH AURCM-5S AURCW-5S
Size Reference RH LH Static Load 3/8" RH AURCM-6S AURCW-6S
1/2" x 1/2"-20 AURPRM-8T AURPRB-8T 23,310 lbs. 1/4" LH AURCB-4S AURCG-4S
5/8" x 5/8"-18 AURPRM-10T AURPRB-10T 25,909 lbs. 5/16" LH AURCB-5S AURCG-5S
3/4" x 3/4"-16 AURPRM-12T AURPRB-12T 34,319 lbs. 3/8" LH AURCB-6S AURCG-6S

143
