2020 DRAG RACING

Pro-Clamp Separators Pro-Crimp Tool II
MSD8843 A must for any tool box. Interchangeable
Keeps plug wires neat and insulated from jaws allow a variety of crimps with one heavy-duty tool. Hardened steel frame
sources of engine heat. Snap-together separators sandwich wires in place. features molded hand grips. Tool includes precision crimping/stripping jaws for
Two 4-wire, two 3-wire, and four 2-wire separators are included. MSD spark plug wire terminals. Other dies are also offered.
Part No. Description Part No. Description
Wire Separators MSD35051 Pro-Crimp Tool II MSD3508 Plug Wire Terminal Dies
MSD3506 Amp Pin Terminal Dies MSD3509 Weathertight Terminal Dies
MSD’s wire separators keep plug wires away from hot MSD3507 Amp Lug Terminal Dies MSD3510 Deutsch Terminal Dies
exhaust, and each other, to prevent inductive crossfire.
Part No. Description Universal Ignition Tester
MSD8841 Dual Plug Wire Separators, 8-8.5mm Wires MSD89981
MSD8842 Dual Plug Wire Separators, Wires With Sleeve NEW!
Ignition tester includes
Firewall Feed-Thru the ability to test traditional single coil
MSD8211 ignitions or coil-per-cylinder applica-
tions. User can create an RPM run,
Rynite and nylon feed-thru that has 1/2" of insulation to insure that maxi-
mum spark reaches the plugs and to prevent voltage leaks from cockpit allowing the ignition to activate accessories
mounted coils. Mounts in a 1" diameter hole in the firewall. like shifters, nitrous selenoids, etc. Tester features a large, easy to read
display and has settings for most popular 4-, 6-, 8- and 12-cylinder engines.
Shrink Sleeving
Single-Channel Digital Ignition Tester
MSD3407
MSD8998
May be used to protect electrical connections Test functions of MSD singl-
of any kind as well as sealing spark plug boots to plug wires. Simply install channel ignitions, including
the sleeve in the desired area and apply heat. Sold in sets of 18.
the Digital-7 Programmable
unit. Produces a simulated
Pro-Heat Guard
trigger signal that fires the ignition. A
MSD3411
spark plug with a very large gap is included for
Heat-resistant woven glass core sleeve is clipping to the coil wire. May also be used to
coated with silicone rubber to resist abrasion and temperatures up to check tachometer and RPM limiter accuracy. Works with 4, 6, or 8 cylinder
1,000°F. Slides over most plug wire. Sold in 25' rolls. engines and simulates up to 16,000 RPM of operation.

Pro-Boot Guard Solid State Relay Block NEW!
MSD3412 MSD7564
Thick, woven fiberglass sleeve is coated with Module replaces four standard relays, helping
silicone rubber and resists extreme temperatures. Sold in 6' roll. to eliminate unsightly wiring. Each channel is
capable of handling 50 amps for up to 8 seconds or 20
Cylinder Markers amps of continuous current. Control electric fans, water pumps, nitrous
MSD3414 solenoids, etc. May be activated with power or ground. Relay block includes
Save time and ensure that the plug wires are built-in over-temp, short circuit, and overload protection.
installed correctly. Molded from plastic, they are available in 8.5mm size.
SPST Relay With Socket Harness
Shrink Sleeves With Cylinder Numbers MSD89611 NEW!
MSD3415 Waterproof SPST relay is rated at 30 amps. Ideal for use
with electric water pumps, fans, fuel pumps, etc. Includes socket harness.
Shrink sleeves are numbered 1-8 and slide over the spark
plug boot for a secure connection.
High Pressure Electric Fuel Pump
MSD2225
Spark Guard
MSD8804 Roller vane pump can stand alone in
multiport EFI’s or work as a “boost-
A dielectric grease that stops voltage leaks, eases boot
removal, simplifies installation, prevents moisture buildup inside the spark plug er” for nitrous oxide systems. It mounts in-line,
wire boots, and protects against radio (RFI) noise. Will not dry up or harden outside of the fuel tank, and delivers 43 GPH @
and retains its spark isolating capabilities indefinitely. Comes in .5 oz. tub. 40 PSI, sufficient fuel flow for up to 500 horsepower. Pump has 3/8" inlet
and 5/16" outlet nipples, includes mounting clamps and hardware.

422
