2020 DRAG RACING

ProClassic Hose Proflex Stainless Steel Braided Hose
Hose is lighter and easier to assemble Stainless steel outer braid, and Chlorinated
than stainless steel braided hose and is Polyethylene (CPL) synthetic liner with
compatible with fuel, oil, or anti-freeze. flexible nylon inner resist abrasion and
The lightweight nylon fiber outer braid will not collapse. Hose has a temperature
with extruded synthetic rubber core has a 350 PSI pressure rating and may range of -40°F to +350°F and is compatible
be used with Full Flow swivel hose ends. with all hydrocarbon and alcohol-based fuels, lubricants, and additives. For
Dash 3 6 10 20 use with Full Flow hose ends.
Size Feet Feet Feet Feet 3 6 10 15 20
-4 RUS632003 RUS632013 RUS632023 — Size I.D. OD. Feet Feet Feet Feet Feet
-6 RUS632053 RUS632063 RUS632073 RUS632093 -4AN 7/32" 1/2" RUS632000 RUS632010 — — —
-8 RUS632103 RUS632113 RUS632123 RUS632143 -6AN 11/32" 9/16" RUS632050 RUS632060 RUS632070 RUS632080 RUS632090
-10 RUS632153 RUS632163 RUS632173 RUS632193 -8AN 7/16" 5/8" RUS632100 RUS632110 RUS632120 RUS632130 RUS632140
-12 RUS632203 RUS632213 RUS632223 RUS632243 -10AN 9/16" 25/32" RUS632150 RUS632160 RUS632170 RUS632180 RUS632190
-12AN 11/16" 29/32" RUS632200 RUS632210 RUS632220 RUS632230 —
ProClassic Crimp-On Swivel Hose Ends -16AN 7/8" 1-1/8" RUS632250 RUS632260 — — —
Aluminum ProClassic hose ends swivel a full
360° and are easy to assemble. Install Twist-Lok Hose
the crimp collar over the hose, push the High-quality economical Twist-Lok hose is
hose onto the fitting, and crimp the col- manufactured using a CPE synthetic rubber
lar with the manual crimper and the proper liner covered with a reinforcing fabric braid, resulting in a product that is
die. (Collars and dies are sold separately.) lightweight and flexible. Hose is pressure rated up to 250 PSI, suitable for
All fittings have a black/silver anodized finish. use with most fuel and oil systems. Not recommended for use with power
Dash Straight 45° 90° 120° 180° steering systems. Compatible with all AN-style fittings. Offered in black only.
Size Hose End Hose End Hose End Hose End Hose End Dash 3 6 10 15 25
-4 RUS610403 RUS610413 — — — Size I.D. O.D. Feet Feet Feet Feet Feet
-6 RUS610463 RUS610473 RUS610483 RUS610493 RUS610513 -4 1/4" 15/32" RUS634343 RUS634353 RUS634103 RUS634113 —
-8 RUS610523 RUS610533 RUS610543 RUS610553 — -6 3/8" 5/8" RUS634363 RUS634373 RUS634143 RUS634153 RUS634163
-10 RUS610583 RUS610593 RUS610603 — — -8 1/2" 23/32" RUS634383 RUS634393 RUS634183 RUS634193 RUS634203
-12 RUS610643 RUS610653 RUS610663 RUS610673 — -10 5/8" 13/16" RUS634403 — RUS634223 — RUS634243

Crimp Collars Twist-Lok Hose Ends
For use with ProClassic crimp-on swivel hose ends. Packs of six. Lightweight aluminum hose ends are up to 40%
Part No. Description lighter than conventional units and are easy
RUS610353 -4 to assemble or disassemble. The 37° sealing
RUS624000
RUS610363 -6 surface is compatible with other manufacturers' hose ends. Fittings are
RUS610373 -8
RUS610383 -10 available in red/blue or black/silver anodizing. For use only with Twist-Lok
RUS610393 -12 hose.
Dash Straight Straight 45° End 45° End 90° End 90° End
Size Blue Black/Silver Blue Black/Silver Blue Black/Silver
-4 RUS624000 RUS624003 — — RUS624150 RUS624153
-6 RUS624010 RUS624013 RUS624080 RUS624083 RUS624160 RUS624163
-8 RUS624020 RUS624023 — RUS624093 RUS624170 RUS624173
-10 RUS624030 RUS624033 RUS624100 RUS624103 RUS624180 RUS624183

Full Flow Hose Ends
Reusable anodized aluminum fittings are lightweight
and durable. Tapered hose ends are easy to assemble.
The 37° angled sealing surface is compatible with other manufacturer’s hose ends. Choose
from blue/red, black/silver, or black anodized fittings in swivel or non-swivel designs.

45° 45° 45° 45° 90° 90° 90° 90°
Dash Straight Straight Straight Swivel Swivel Non-Swivel Swivel Non-Swivel Non-Swivel Non-Swivel Swivel
Size Blue/Red Black/Silver Black Blue/Red Black/Silver Black Black Blue/Red Black/Silver Black Black
-4AN RUS610010 RUS610013 RUS610015 RUS610080 — RUS610085 — RUS610150 — RUS610155 —
-6AN RUS610020 RUS610023 RUS610025 RUS610090* RUS610093 RUS610095* — RUS610160* RUS610163* RUS610165* —
-8AN RUS610030 RUS610033 RUS610035 RUS610100* RUS610103 RUS610105* — RUS610170* RUS610173* RUS610175* —
-10AN RUS610040 RUS610043 RUS610045 — — RUS610115* — RUS610180* RUS610183* RUS610185* —
-12AN RUS610050 — RUS610055 — — RUS610125 RUS613125 — — RUS610195 RUS613195
* Only available in swivel-style hose end.
