2020 DRAG RACING

Super T-10 Manual Transmission
An improved version of the original T-10, fully redesigned transmission is 50% more durable and weighs 10
lbs. less than its predecessor. Engineered to deliver improved acceleration, four-speed countershaft, helical gear
transmission is synchronized in all forward gears. First and reverse are “constant mesh” to prevent gear “clash”, and
strut-type synchronizers are used to ease shifting and increase durability. Aluminum-cased unit weighs just 70 lbs. Stocked in three versions, each transmis-
sion features a low first gear ratio, while retaining relatively close ratio spacing between second, third, and fourth gears to minimize RPM “drop” during
each gear change for maximum performance. Bellhousing, flywheel, and clutch components must be purchased separately.

Torque Ratios
Part No. Description Capacity 1st 2nd 3rd 4th Reverse
RIC1304000069 Super T-10 325 ft./lbs. 2.64 1.75 1.34 1.00 2.55
RIC1304000070 Super T-10 375 ft./lbs. 2.43 1.61 1.23 1.00 2.35
RIC1304000072 Super T-10 300 ft./lbs. 2.88 1.33 1.33 1.00 2.78

Ring And Pinion Sets

Richmond is an industry leader in the manufacturer of high-performance ring and pinion sets. Street Gear ring and pinion sets, made of 8620 steel, have
excellent wear characteristics and are versatile enough for street or mild drag race use. Pro Gear ring and pinion sets, made with high-impact 9310 steel,
are engineered to take the abuse of high-horsepower drag race-only cars (not for street use). Gasket diagrams are shown for differential identification.

Chrysler 8.75" (Early) Ford 8.8"
• Housing, 10 Holes, Casting 742, Part No. Ratio Teeth • Housing, 10 Holes, 10-9/16" x 10-13/16"
8-11/16" x 10-19/32" Street Gear (Early) • 8.8" Diameter Ring Gear
• 12-Bolt Carrier RIC69-0375-1 3.91 43-11 • 1.626" Diameter Pinion, 30-Spline
• 8.75" Diameter Ring Gear RIC69-0045-1 4.10 41-10 • 1981-98 Ford Trucks And ’85-98 Mustangs
• 1.75" Dia. Straight Pinion, 10-Spline RIC69-0046-1 4.30 43-10 • Installation Kit: RIC83-1043-1
• 1957-68 Chrysler, RIC69-0047-1 4.57 32-7
Plymouth, And Dodge Passenger Cars RIC69-0048-1 4.86 34-7 Part No. Ratio Teeth
• Installation Kit: RIC83-1037-1 RIC69-0145-1 5.13 41-8 Street Gear
RIC49-0103-1 3.55 39-11
RIC49-0104-1 3.73 41-11
Chrysler 8.75" (Late) RIC69-0310-1 4.10 41-10
• Housing, 10 Holes, Casting 489, RIC69-0376-1 4.33 39-9
8-11/16" x 10-19/32" Part No. Ratio Teeth RIC69-0312-1†† 4.56 41-9
• 12-Bolt Carrier Street Gear (Late) RIC69-0382-1†† 4.88 39-8
• 8.75" Diameter Ring Gear RIC69-0058-1 3.91 43-11 INSTALLATION NOTES FOR FORD 8.8": †† Needs special cross pin RIC80-0273-1.
• 1.875" Dia. Tapered Pinion, 10-Spline RIC69-0059-1 4.10 41-10 Will not fit 1987-97 trucks.
RIC69-0060-1 4.30 43-10
• 1969-73 Chrysler, Plymouth,
And Dodge Passenger Cars RIC69-0061-1 4.57 32-7 Ford 9"
RIC69-0062-1 4.86 34-7
• Installation Kit: RIC83-1031-1 • Oval Housing, 10 Holes
• 10-Bolt Carrier
• 9.00" Diameter Ring Gear
Dana 60 • 1.313" Diameter Pinion, 28-Spline
• Housing 12-1/8", 10 Holes • 1957-87 Ford Cars And Trucks
• 12-Bolt Carrier • Installation Kits:
• 9.750" Diameter Ring Gear RIC83-1011-1 (2.891" Carrier Bearing), RIC83-1013-1 (3.062" Carrier Bearing)
• 1.626" Diameter Pinion, 29-Spline Part No. Ratio Teeth Part No. Ratio Teeth
• 1966-73 Dodge And Plymouth Cars, 1966-98 AMC, Street Gear Pro Gear
Ford, Dodge, And GM Trucks RIC69-0177-1 3.89 35-9 RIC79-0001-1 3.40 34-10
• Installation Kit: RIC83-1034-1 RIC69-0179-1 4.11 37-9 RIC79-0002-1 3.50 35-10
RIC69-0367-1 4.22 38-9 RIC79-0004-1 § 3.70 37-10
Part No. Ratio Teeth Part No. Ratio Teeth §
Street Gear Pro Gear RIC69-0161-1 4.33 39-9 RIC79-0043-1 § 3.89 35-9
4.11
37-9
RIC69-0368-1
RIC79-0045-1
40-9
4.44
RIC69-0052-1 4.10 41-10 RIC79-0011-1 4.10 41-10 RIC69-0185-1 4.56 41-9 RIC79-0079-1 § 4.29 30-7
RIC69-0053-1 4.56 41-9 RIC79-0077-1 4.56 41-9 ^
RIC69-0054-1 4.88 39-8 RIC79-0068-1 4.88 39-8 RIC69-0067-1 4.86 34-7 RIC79-0098-1 § 4.29 30-7
RIC69-0057-1 5.13 41-8 RIC79-0013-1 5.38 43-8 RIC69-0360-1 5.00 35-7 RIC79-0080-1 § 4.57 32-7
RIC79-0041-1 6.17 37-6 RIC69-0068-1 5.14 36-7 RIC79-0060-1 4.86 34-7
INSTALLATION NOTES FOR DANA 60: RIC69-0270-1 5.29 37-7 RIC79-0066-1 4.86 34-7
Gear sets listed fit 4.56 and numerically higher carrier only RIC69-0069-1 5.43 38-7 RIC79-0078-1 5.00 35-7
RIC79-0017-1
35-6
36-7
5.14
5.83
RIC69-0288-1
RIC69-0199-1 6.00 36-6 RIC79-0005-1 5.43 38-7
RIC69-0290-1 6.20 31-5 RIC79-0007-1 5.67 34-6
RIC69-0276-1 6.33 38-6 RIC79-0019-1 5.83 35-6
RIC69-0197-1 6.50 39-6 RIC79-0054-1 6.50 39-6
§ 35-spline pinion support. ^ Special 9.5" 35-spline gear set. Housing must be modified for
larger ring gear.
