2020 DRAG RACING

High-Performance 74-Series Long Master Cylinder Kits
4000 Series Super Starters Universal kits have side or flange-mount capabil-
The Super Starter is not affected by hot or ity, easy interchange of remote reservoir,
cold conditions, and the low (250 amp) and a mounting bracket that adapts
current draw allows more spark for firing large or small reservoir to remote
the engine. The 3.75:1 gear reduction mount. Each master cylinder (5.6"
starter produces 50% more torque, yet long) kit includes lightweight alumi-
weighs just 11.2 lbs. num master cylinder featuring dual fluid
Part No. Description outlets and bleed screws, small (4.0 oz.) and large (10.7 oz.) reservoirs,
TIL54-40001 Chevy V-8, 90° V-6, 153 Or 168T Ring Gear remote reservoir mount kit, 3/16" inverted flare, and -3AN adapter fittings.
TIL54-40013 Ford SB 289-351W, 351C, BB 390-428 “FE”, 1967-Up Outlet size is -3AN, 3/8"-24 thread.
TIL54-40014 Ford 351M-400, BB 429-460 Universal Master Cylinder Rebuild
Description Master Cyl. Kit Only Kit
Replacement Components
5/8" Bore Master Cylinder TIL74-625U — TIL74-625RK
TIL54-422HD Heavy Duty Solenoid, 4000 Series NEW!
7/10" Bore Master Cylinder TIL74-700U — —
TIL54-421 Drive Assembly, For 54-40001, 54-40013 And 54-40014
3/4" Bore Master Cylinder TIL74-750U TIL74-750 TIL74-750RK
TIL54-442 Pinion Kit, For 54-40001, 54-40013 And 54-40014
13/16" Bore Master Cylinder TIL74-812U — TIL74-812RK
TIL54-446 Return Spring Kit For Starter Pinion, Includes Spring, Cap And Clip
7/8" Bore Master Cylinder TIL74-875U TIL74-875 TIL74-875RK
TIL54-950 Shim Kit, .062" Thick, Shim Selection And Chevy Mounting Bolts
1" Bore Master Cylinder TIL74-1000U TIL74-1000 TIL74-1000RK
TIL54-952 Shim Kit, .062" Thick, Round And Housing Shaped
1-1/8" Bore Master Cylinder TIL74-1125U — —
Cooler Pump TIL40-527
Master Cylinder Replacement Parts For 74-Series
Ideal for pumping engine oil or transmission fluid
through a cooler when the engine is shut down, Tilton brake offers quality replacement master cylinder components.
self-priming pump flows 1-2 GPM and
includes an integral fan. Pump has
3/8" NPT ports that may be rotated
in 90° increments to ease plumbing.
Universal mounting plate is included.
Choose from intermittent (3.5 lbs.) or continuous duty (5.5 TIL74-200 TIL74-203 TIL74-207
lbs.) pumps with Buna or Viton diaphragm and check valve.
Part No. Description
Part No. Description
TIL73-820 -3AN Male Union
TIL40-524 Intermittent Duty Cooler Pump, Buna Diaphragm
TIL74-200 Inlet Fitting
TIL40-525 Intermittent Duty Cooler Pump, Viton Diaphragm
TIL74-202 Small Reservoir (4.0 Oz.)
TIL40-527 Continuous Duty Cooler Pump, Buna Diaphragm TIL74-203 Medium Reservoir (6.8 Oz.)
Notes: Intermittent pumps are designed to operate 1-2 hours with a 15-minute cool down;
continuous-duty units are for applications where the pump must run for longer than 2 hours at TIL74-204 Large Reservoir (10.7 Oz.) (74 Series Only)
a time without cool down. Models with Buna diaphragm/check valve are for use with standard TIL74-207 Cap, 4.0, 6.8, And 10.7 Oz. Reservoir
oils and coolants; pump with Viton diaphragm/check valve are for use with corrosive fluids TIL74-208 Clamp, Each
including alcohol.
TIL74-212 Reservoir Adapter
TIL74-212-A O-Ring For Master Cylinder
73-Series High Volume Integral Reservoir
TIL74-214 24" Rubber Hose
Master Cylinders
TIL74-400 Push Rod (74 Series Only)
Die-cast aluminum master cylinders with TILTE2089-188L 3/16" Inverted Flare To -3AN Male Fitting
internal baffling have a leak-free, integral
reservoir with a large 10-oz. capacity.
Cylinders have a reliable seal/piston and a Racing Brake Fluid
1/8" NPT outlet port.
TILTBR-1
Part No. Description
Designed for the semi-professional or sportsman racer, fluid
TIL73-750 Master Cylinder, 3/4" Bore
has a dry boiling point of 590°F. Sold in 8.5-oz. bottle.
TIL73-875 Master Cylinder, 7/8" Bore
TIL73-1000 Master Cylinder, 1" Bore
