Sportsman Bump Stop Springs And Retainers Single Taper Urethane Bump Stops
Designed with the sportsman dirt and pavement racer in mind. No Offer a rate change once the tapered top is closed out.
hysteresis like urethane bump stops. More consistent with tempera- Part No Description
ture variations. Smaller package design than Pro-Series. PACPAC-BR110 2.00" X 1.00" X .650", Orange
Rate 1.700" O.D. x 1.000" Tall 1.190" O.D. x 2.125" Tall PACPAC-BR111 2.00" X 1.00" X .650", Black
600 PACPAC-B1X1.70X600 PACPAC-B2X1.19X600 PACPAC-BR112 2.00" X 1.00" X .650", Purple
700 PACPAC-B1X1.70X700 PACPAC-B2X1.19X700 PACPAC-BR113 2.00" X 1.00" X .650", Green
PACPAC-BR114 2.00" X 1.00" X .650", Yellow
800 PACPAC-B1X1.70X800 PACPAC-B2X1.19X800
PACPAC-BR115 2.00" X 1.00" X .650", Red
900 PACPAC-B1X1.70X900 PACPAC-B2X1.19X900
“Tree” Shape Urethane Bump Stop
Bump Spring Kits PACPAC-KS112
Part No Description
These specialized kits can be used on any
shock absorber with a 1/2" shaft. Each kit PACPAC-BTR203 2.00" X 3.00" X .650", Yellow
PACPAC-BTR208
2.00" X 2.00" X .650", Yellow
contains seven springs of varying
rates and needed corresponding
cups. Kit includes 1/2" hole, four Elliptical Urethane Bump Stops
1" springs 200/300/500/800, Offers a uniform rate profile that is
three 2" springs 400/500/600. considered progressive as the profile
closes out.
Torsion Bar Retaining Caps Part No Description
PACPAC-BR101 2.00" X 1.00" X .650", Orange, 40 Durometer
Part No. Description
PACPAC-BR102 2.00" X 1.00" X .650", Black, 50 Durometer
PACPAC-300718-438 7/8" Bar, K48 PACPAC-BR103 2.00" X 1.00" X .650", Purple, 60 Durometer
PACPAC-300718-625 1" Bar, L48 PACPAC-BR104 2.00" X 1.00" X .650", Green, 70 Durometer
PACPAC-300718-750 1-1/8" Sprint Bar PACPAC-BR105 2.00" X 1.00" X .650", Yellow, 80 Durometer
PACPAC-BR106 2.00" X 1.00" X .650", Red, 85 Durometer
Bump Stop Hardware
Use this hardware to mount and align the
urethane hardware to your desired stack
setup.
Part No Description
Bump Stop, Aluminum,
PACPAC-C280
Washer/Spacer, 1.975" X .505" X .100"
Bump Stop, Aluminum,
PACPAC-C281
Washer/Spacer, 1.975" X .630" X .100"
PACPAC-C282 Bump Stop Cup, Aluminum, 2.300" X .050" X 2.000"
PACPAC-C283 Bump Stop Cup, Aluminum, 2.300" X .630" X 2.000"
PACPAC-C284 Bump Stop Taper Spacer, Aluminum, 2.300" X .050" X .950"
PACPAC-C285 Bump Stop Taper Spacer, Aluminum, 2.300" X .630" X .950"

Tubular Torsion Bars
PAC/Schroeder uses only aircraft quality high alloy steel to manufacture the finest torsion bar possible, and machines their torsion bars
with state-of-the-art CNC equipment. Only PAC/Schroeder torsion bars are machined in one continuous pass from end to end in order to
prevent irregularities. They are then polished, heat treated to exact specifications, then polished again to assure no surface imperfections ex-
ist which could cause a stress point or crack to originate. Bars are then coated with a protective film and shipped in plastic screw-lock tubes
for protection and easy identification.
Part No. Part No. Part No. Part No.
23" x 3/4" 26" x 1" 29" x 1-1/8" 31" x 1-1/8"
PACPAC-TB-J48-650-23S PACPAC-TB-L48-750-26R PACPAC-TB-M48-937-29S PACPAC-TE-M48-100-31H
PACPAC-TB-J48-670-23S PACPAC-TB-L48-775-26R 30" x 1-1/8" PACPAC-TE-M48-101-31H
PACPAC-TB-J48-730-23S PACPAC-TB-L48-800-26R PACPAC-TB-M48-925-30H PACPAC-TE-M48-102-31H
PACPAC-TB-J48-740-23S PACPAC-TB-L48-825-26R PACPAC-TB-M48-950-30H PACPAC-TE-M48-103-31H
26" x 7/8" PACPAC-TB-L48-850-26R PACPAC-TB-M48-975-30H PACPAC-TE-M48-105-31H
PACPAC-TB-K48-650-26R PACPAC-TB-L48-875-26R PACPAC-TB-M48-987-30H PACPAC-TE-M48-106-31H Detail of PAC/Schroeder
PACPAC-TB-K48-675-26R 28" x 1" PACPAC-TB-M48-100-30H PACPAC-TE-M48-925-31H Torsion Bar
PACPAC-TB-K48-700-26R PACPAC-TB-L48-775-28R PACPAC-TB-M48-101-30H PACPAC-TE-M48-950-31H
PACPAC-TB-K48-725-26R PACPAC-TB-L48-800-28R PACPAC-TB-M48-102-30H PACPAC-TE-M48-975-31H
PACPAC-TB-K48-750-26R PACPAC-TB-L48-825-28R PACPAC-TB-M48-135-30 PACPAC-TE-M48-987-31H
PACPAC-TB-K48-775-26R PACPAC-TB-L48-850-28R PACPAC-TB-M48-105-30H
PACPAC-TB-K48-800-26R PACPAC-TB-M48-106-30H
26" and 28" torsion bars have a 1" spline diameter, are gun drilled 7/16" to reduce weight.
