Page 300 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Plasma-Moly File Fit Plasma-Moly Standard Gap
Piston Ring Sets Piston Ring Sets
Perfect Circle Rings reduce friction, Same quality as file-fit rings, but ready
increase power output, reduce oil consump- to install. Sets are only available with
tion and last longer. File fit sets include eight standard tension oil rings.
ductile iron plasma-moly top rings, THG Bore Top Second Oil
(tapered hook groove) second compression Part No. Size Ring Ring Ring
rings and CP-20 oil control rings. Ring sets PER315-0036 4.000" 1/16" 1/16" 3/16"
include standard tension oil rings unless PER315-0036.030 4.030" 1/16" 1/16" 3/16"
specified.
PER315-0049.030* 4.030" 1/16" 1/16" 3mm (Low Tension)
Bore Top Second Oil
Part No. Size Ring Ring Ring PER315-0033.030 4.030" 1/16" 1/16" 1/8"
PER315-0036.005 4.000" 1/16" 1/16" 3/16" PER315-0036.040 4.040" 1/16" 1/16" 3/16"
PER315-0005.005* 4.000" 1/16" 1/16" 3/16" (Low Tension)
PER315-0049.040* 4.040" 1/16" 1/16" 3mm (Low Tension)
PER315-0036.025 4.020" 1/16" 1/16" 3/16"
PER315-0036.035 4.030" 1/16" 1/16" 3/16" PER315-0036.060 4.060" 1/16" 1/16" 3/16"
PER315-0005.035* 4.030" 1/16" 1/16" 3/16" (Low Tension) PER315-0033.060 4.060" 1/16" 1/16" 1/8"
PER315-0033.035 4.030" 1/16" 1/16" 1/8" * Reduced radial wall tension.
PER315-0034.045 4.040" 5/64" 5/64" 3/16"
PER315-0036.045 4.040" 1/16" 1/16" 3/16"
PER315-0005.045* 4.040" 1/16" 1/16" 3/16" (Low Tension)
PER315-0036.065 4.060" 1/16" 1/16" 3/16" PFC PAD PART NUMBERING SYSTEM
PER315-0005.065* 4.060" 1/16" 1/16" 3/16" (Low Tension)
PER315-0004.005* 4.125" 1/16" 1/16" 3/16" (Low Tension) WWW-XX-YY-ZZ
PER315-0073.005 † 4.125" 1/16" 1/16" 3/16"
PER315-0032.005 4.125" 1/16" 1/16" 3/16" PFC Pad Shape Compound Overall Thickness (mm) 04= Standard Set, 4 Pads
PER315-0032.025 4.145" 1/16" 1/16" 3/16" 44 = Race Ready, 4 Pads
PER315-0004.035* 4.155" 1/16" 1/16" 3/16" (Low Tension)
PER315-0032.035 4.155" 1/16" 1/16" 3/16"
PER315-0032.045 4.165" 1/16" 1/16" 3/16"
* Reduced radial wall tension

PFC Racing Compounds
Performance Friction pads are used by many top short track racers. Select the PFC compound listed
below that best suits requirements. All sets are completely race ready pads requiring no bedding. All
pads are boxed per axle set, four pads per box. All PFC compounds are painted black.
Compound Description
High friction, new generation compound delivers the ultimate stopping power. Developed from the 01 compound with the added bonuses of
increased bite and modulation, while offering superior disc conditioning and release characteristics for exceptional control. Compound works well
13
with severe braking applications including heavy, fast or high downforce cars. Wear is similar to 01 compound. Will operate at higher temperatures,
if required and has a high fade resistance. Pad additionally has shown to have the lowest taper wear in a properly designed race caliper.
Lighter, medium distance friction compound combines the benefits of ultimate braking control and superior disc conditioning. Also developed from
14 the 01 compound, pads offer lower cold bite and reduced wheel lock-up at the end of a stop. Higher thermal stability. Compound works well with
medium to low grip venues where control and modulation is at a premium.

Part No. Description Part No. Description
Wilwood Dynalite, Outlaw 2000, Wilwood Dynalite Single, Outlaw 1000, Sierra Mini GN
Sierra Mini GN PFR7751-14-20-44 14 Compound, Race Ready Set
PFR7752-01-12-44 14 Compound, Race Ready Set
Part No. Description
Wilwood Dynalite Bridgebolt, Outlaw 2800
PFR7754-14-16-44 14 Compound, Race Ready Set
RH665 DOT 4 Racing Brake Fluid
Brake Rotors A specially formulated synthetic brake fluid engineered
PFC’s late model/modified brake rotors are specifically for racing applications and the associated
made from superior alloys to resist cracking and high temperatures. Complex mixture provides excep-
are offered in smooth or slotted designs. Direc- tional viscosity, lubricity, compressibility and a “rock
tional vanes control air flow and increase brake hard” pedal at extreme temperatures with a very high
performance and durability. Advanced pattern boiling point, while also meeting stringent FMVSS 116
on slotted rotor enhances pad bite and reduces DOT 4 specifications. RH665 has the highest guaran-
thermal distortion. All rotors listed are 8-bolt with a teed minimum (ERBP) dry boiling point of any DOT 4
7" bolt circle. brake fluid, 617°F. Sold in 500ml bottles, or in cases.
PFC Pad Part No. Description
Part No. Description Shape
PFR25-0037 RH665 Brake Fluid, 500ml Bottle
PFR299-20-0045-01* LH, 11-3/4" Dia. x .810" Thick 0052/7752/7754 PFR25-0038 RH665 Brake Fluid, Case of (12) 500ml Bottles
PFR299-20-0045-02* RH, 11-3/4" Dia. x .810" Thick 0052/7752/7754
* Includes rotor bolt kit
299
