Page 303 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

One Way Valve Pop Off PTR08-0450
In-Tank Fuel Filters Breather assembly is installed in valve cover on
Filters are race proven by the World of Outlaws. Stainless, pleated engine’s running crankcase in vacuum condition.
filters, available in straight and 90° styles, easily attach by slipping Valve seals engine from air entering engine, but
the pick-up hose over the 3/4" neck and securing with a clamp. opens in the event of crankcase pressure, allowing
Part No. Description crankcase to vent. Includes -12AN bung to weld to
PTR09-1460 Straight, 60 Micron aluminum valve cover.
PTR09-1461 90°, 60 Micron
PTR09-1481 90°, 45 Micron
Screw-In Breather PTR08-0415
Dry Sump Pan Filter Internally baffled breather has -12AN male threads to fit
Billet aluminum filter bolts directly bung on Peterson dry sump tanks. May also be used
to the pan fitting. Screen protects dry on valve covers.
sump pump from engine debris and
can be inspected without removing
pan. 2-1/4" long body.
Dry Sump Oil Tanks
Part No. Description
PTR09-0404 Filter With -12AN Fitting “New Generation” oil tanks are built with state-of-the-
PTR09-0411 Replacement Screen art com po nents and internal baffling, which prevents
oil aeration while helping to maintain a tall column of
PTR09-0405 oil over the pick-up. Easily disassembled, tops can be
Scavenge Filters
ro tated for easy placement of fittings. Brackets sold
Peterson’s aluminum billet inline separately.
filters remove harmful debris from
Part No. Description
the oil before it reaches the pump. The free-flowing units have twice
the filter area of dry sump pan screens. PTR08-0005* 2 Gal. Single Scavenge Inlet,
19-1/2" H x 6" Dia.
Part No. Description 2.5 Gal. Single Scavenge Inlet,
Inline Scavenge Filters PTR08-0007* 24" H x 6" Dia.
-8AN, Use On Lifter Valley Scavenge
PTR09-0401 PTR08-0008* 2.5 Gal. Dual Scavenge Inlet, 24" H x 6" Dia.
Or With Rear End Pumps
-10AN, Use With Dry Sump Pan PTR08-0009* 3 Gal. Single Scavenge Inlet, 16" H x 9" Dia.
PTR09-0402 PTR08-0011 † 4 Gal. Single Scavenge Inlet, 19" H x 9" Dia.
Or Lifter Valley Scavenge Lines
PTR09-0403 -12AN, Use With Dry Sump Pan Lines PTR08-0110 Replacement O-Ring For 6" Dia. Tanks
PTR09-0405 -16AN * Use mount bracket PTR08-0100.
Inline 90° Scavenge Filters † Use mount bracket PTR08-0101.
-8AN, Use On Lifter Valley Scavenge
PTR09-0406
Or With Rear End Pumps
-10AN, Use With Dry Sump Pan Oil Pressure Gauge Fittings
PTR09-0407
Or Lifter Valley Scavenge Lines
Special fittings, designed by Karl Kinser, gets the oil pressure
PTR09-0408 -12AN, Use On Dry Sump Pan gauge line up where it is more accessible. Fitting is 1/8" NPT on
Replacement Screens engine end, while the gauge connection is -4AN.
PTR09-0410 Fits PTR09-0402, PTR09-0403, PTR09-0407, PTR09-0408
PTR09-0411 Fits PTR09-0401, PTR09-0406
Y-Manifolds PTR15-1040 PTR15-1041
Part No. Description
When multiple oil lines need to be com-
bined in a single high flow line, the tubular or PTR15-1040 Oil Pressure Gauge Fitting, 90°
billet aluminum Y-manifolds get the job done. PTR15-1041 Oil Pressure Gauge Fitting, Straight
PTR10-0041
Part No. Description
PTR10-0033 Y-Manifold, Billet Aluminum, -10, -8, -8 SB Chevy Lifter Valley Riser Tubes
PTR10-0041 4-Way Y-Manifold, Billet Aluminum, -8, -6, -6, -6 PTR15-1050
PTR10-1721 Y-Manifold, Aluminum Tube, -12, -12, -12
PTR10-1725 Y-Manifold, Aluminum Tube, -16, -12, -12 Tubes are installed in the lifter drain back
PTR10-1735 Y-Manifold, Aluminum Tube, -16, -16, -16 holes to prevent oil drain back while still
allowing the engine to “breathe”. Filter screens rated
at 70 micron are installed in the tube opening. Installation
Oil Filter Block Off Plates requires that the lifter drain back holes be tapped to 1/4" NPT. Hex
Oil filter block off plates fa cil i tate the top is 9/16" and bottom is 1/4" NPT. Set of eight.
installation of wet and dry sump oil pres-
sure lines to the stock oil filter pad. Plates
are made from alu mi num billet and include Fuel Fittings
mount ing hard ware. Machined from aluminum and anodized, fittings have large bores
Part No. Description and are radiused on the inlet sides for optimum flow.
PTR09-0002 Chevy V8 With -12AN Fitting Part No. Description
PTR09-0004 Chevy Bow Tie Block With -12AN Fitting PTR15-1002 Fuel Regulator, -10 x -8 Port
PTR09-0020 Replacement Square O-Ring For 09-0001 Thru 09-0004 PTR15-1003 Fuel Regulator, -6 x -6 Port
PTR15-1004 Fuel Regulator, -8 x -8 Port
