Page 304 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Dry Sump Oil Tank Mounting Brackets PTFE Engine Seals
Mounting brackets are machined from billet alumi- Hard-to-find PTFE engine seals assure maximum vacuum levels for
num and include EPDM rubber-lined stainless steel engines with dry sump oil systems. Seals are manufactured by TKO
straps. Sold in pairs. Competition Development.
Part No. Description Part No. Description
PTR08-0100 For 6" Dia. Tanks PTRSM86410 Rear Main Seal, SB Chevy 400
PTR08-0101 For 9" Dia. Tanks PTRSM86586 Jesel Front Cover, Chevy Cam Seal
PTRSM86587 Jesel Front Cover, SB Chevy Crank Seal
Dry Sump Tank Fittings PTRSM86625 Rear Main Seal, SB Chevy 350
Anodized aluminum fittings complete the installation of any Peter- PTRSM86990 Front Crank Seal, SB Chevy
son dry sump tank.
Part No. Description SB Chevy Manifold End Rail Spacers
PTR08-0501 -10AN Hose x -12AN Port Fill the gap between the manifold and
PTR08-0502 -12AN Hose x -12AN Port the lifter valley end rails when using raised
PTR08-0503 -16AN Hose x -12AN Port
PTR08-0504 -6AN Port Plug (Tank Drain) port cylinder heads on small block Chevy
PTR08-0505 -12AN Port Plug (Tank Drain) engines. Sold in pairs, spacers include four
PTR08-0506 O-Ring Kit, -12AN (5 Per Pack) 3/16" roll pins for retention. Drilling of the
block is required for installation.
Inline Ball Valves Part No. Description
PTR09-1060 Spacer Set, .125" Thick
CNC-machined from aluminum billet, PTR09-1061 Spacer Set, .187" Thick
then anodized for durability, Peterson’s PTR09-1062 Spacer Set, .250" Thick
ball valves for inline mounting have PTR09-1063 Spacer Set, .375" Thick
PTFE seals and hardcoated aluminum
balls and bodies for long life and resis-
tance to corrosion from racing fuel. Valves are available with small Oil Tank Heaters
bodies in -6AN and -8AN sizes and large bodies in -10AN and -12AN Pre-heating of dry or wet sump systems
sizes. A panel mount ball valve (-6AN) is also available and is ideal on a race engine ensures good lubrica-
for use as a dash mounted fuel shutoff. tion upon initial start-up. Immersion-style
heater does a great job of pre-heating and
Part No. Description
PTR09-0900 Small Body Valve -6AN only requires welding a threaded bung into
PTR09-0910 Panel Mount Ball Valve -6AN Male Fittings the tank. Wrap around styles can be glued
PTR09-0923 Ball Valve, -8AN Male To -8AN Female to the outside of the tank or pan.
PTR09-0960 Large Body Valve -12AN x -12AN Part No. Description
300 Watt Immersion Style, 110 Volt With Detachable Cord Set,
PTR08-0300 Steel And Aluminum 1/2" NPT Weld Bungs
Remote Oil Filter Mounts 300 Watt Wrap Around Pad, 2" x 15", 110 Volt With
Manufactured from billet, 6061-T6 aluminum PTR08-0301 Detachable Cord Set, Attaches With Hi-Temp RTV Silicone
for rigidity, remote mounts are offered to ac- PTR08-0302 400 Watt Wrap Around Pad, 4" x 10", 110 Volt With
cept popular oil filters. Mounts include -12AN Detachable Cord Set, Attaches With Hi-Temp RTV Silicone
inlet and outlet ports, and an 1/8" NPT gauge port. Sold
complete with fittings.
Lightweight Cap
Part No. Description And Bung Assembly PTR08-0611
PTR09-1301 Accepts 13/16" Thread Chevrolet Filter, -10AN Fittings
Billet aluminum 1-7/16" cap and bung as-
PTR09-1302 Accepts 13/16" Thread Chevrolet Filter, -12AN Fittings sembly is ideal when fabricating custom tanks.
PTR09-1312 Accepts 3/4" Thread Ford Filter, -12AN Fittings
Cap is red anodized.

V12 Reverse Brake Bleeder PHS2003-B
The V12 reverse brake bleeding system is designed for
light duty professional use. Reverse
brake bleeder is manufactured
from Zytel nylon that resembles the
MaxProHD Reverse Brake Bleeder strength of steel. Rebuildable unit
PHS2002HD-B offers a virtual lifetime of use.
Sold complete with required tub-
New and improved, the MaxProHD
Reverse Brake Bleeder allows performing ing, adapters and users manual.
one-person brake services. System func-
tions by removing trapped air in the brake V5 DIY Reverse Brake Bleeder
system by pushing it up and out the master PHS2104-B
cylinder for a firm pedal. Die cast steel and Economical, yet powerful reverse brake
aluminum bodied unit features an improved
check valve system and spring tension adjust- bleeding system is designed for the do-it-
yourselfer. System delivers all bleeding opera-
ment, while optimized hydraulic ratios provide
smooth operation with minimal hand force. Sold tions in a small package. Sold complete with
required tubing, adapters and users manual.
complete with required tubing, adapters and users manual.
303
