Page 365 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Sprint Air Horn Seal Rod End Boots SICRERS36PK
Seal works regardless of vibration or Enclosed boots isolate rod ends from dirt, mois-
variations in tube diameter. Prevents ture and corrosion. Ideal for high misalignment
dirt from entering air box and includes applications. In sets of six, rod end boots fit 1/2",
aluminum base. Sold individually; four 5/8" and 3/4" SAE, male or female rod ends.
required for V8’s.
Part No. Description Firewall Grommets
SICSEIT3001 2-1/2"-2-3/4" Stacks
SICSEIT3002 2"-2-1/2" Stacks Grommets may be fastened to firewall with rivets or screws to pro-
SICSEIT3003 2-3/4"-3" Stacks vide a leakproof passage for hoses or wires. Eliminate sharp edges
which cause electrical shorts or fluid leakage.

Camber Adjustment Kit
SICCA860KS
Redesigned original adjustment kit to
allow the racer to change camber at the
track in a matter of minutes. Kit lets the front Part No. Description
axle lean to just the perfect angle, placing the SICGS10034 3" Diameter, -4AN Hose
front tires flat on the race track. SICGS10036 3" Diameter, -6AN Hose
Part No. Description SICGS10038 3" Diameter, -8AN Hose
Replacement Sleeves SICGS100310 3" Diameter, -10AN Hose
SICCA860S0 Gold 0° SICGS100312 3" Diameter, -12AN Hose
SICCA860S5 Silver .5° SICGS100316 3" Diameter, -16AN Hose
SICCA860S1 Blue 1.0°
SICCA860S15 Red 1.5° SICGS100320 3" Diameter, -20AN Hose
SICGS1003BL 3" Diameter, Blank
SICGS20035 1-1/2" Diameter, Blank
Rod End Seals SICGS404BL 4" Diameter, Blank
Rod end seals keep dirt and water out SICGS50238BL 2" Diameter, Blank
of rod ends, insuring longer life and better SICGS101NHBL Double Hole Grommet, (2) 3" Diameter, Blank
per for mance. Excellent for use on dirt
cars. Comes in 6 packs.
Part No. Description Pointed Firewall Grommet
3/8" Rod End,
SICWS37506PK SICGS4001WPT
6-Pack
1/2" Rod End, Ideal for running throttle linkage, oil pressure
SICWS50016PK
6-Pack lines, battery cables, etc. Grommet has a 2"
diameter and a pointed design with no hole.
Torque Tube Seals
Seals-It torque tube seals prevent hot grease
from running out of torque tube and possibly burn-
ing driver. Gauge Isolators
Part No. Description Use between gauge and dash or gauge
2.500" ID Torque Tube panel to dampen vibration.
SICTT4500
Seal, Gold Part No. Description
2.562" ID Torque Tube SICDB206225 2-1/16" Gauge Isolator
SICTT4562
Seal, Blue SICDB260275 2-5/8" Gauge Isolator
Torque Ball Housing Seals
Available for aluminum “MPD” and steel
“DMI” bellhousings, seals fit Chevrolet en-
gines with 3.580" crank flange diameter using
motor plates that are 3/8" thick with a thick-
ness variation of +/- 1/64" and center holes
with 6.0" +/- 1/64" diameter. Seals may fit other
housings as well, but we recommend careful
checking before installation. Both types are supplied with
black anodized rings around the seal and hard coat anodized cups.
Part No. Description
SICTBS1A07 Torque Ball Seal Assy. For MPD Style Housing
SICTBS2A07 Torque vBall Seal Assy. For DMI Style Housing
SICTBS2C07 Replacement Cup Only For DMI Style Housing
SICTBS2S07 Replacement Seal Only For DMI Style Housing
