Page 360 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Pro Copper, Pro Copper Exhaust Gaskets
Titan And Titan ICS SCE offers exhaust gaskets made of dead soft copper, a very
Head Gaskets SCEP11063 - Pro Copper durable material that will never blow out. Sold in pairs
Pro Copper head gaskets are
made from C-1100 ASTM B152-92
copper sheet, annealed to Rock-
well F-32. Titan copper head gas- Part No. Description Port Type
kets combine great strength with SCET36064 - Titan Small Block Chevrolet 262-400
built-in offset fluid seals. Pro Copper SCE4011 Pro Copper Embossed Round 1.50" Dia.
and Titan gaskets require that the SCE4111 Pro Copper Embossed 18° Heads
block or cylinder head be O-ringed.
O-ring wire must be purchased SCE4211 Pro Copper Embossed Square 1.500" x 1.437"
separately. Titan ICS copper head SCES36064 -Titan ICS SCE4311 Pro Copper Embossed “D” Port w/1.75" Dia. Primary Tube
gaskets, strong enough for extreme compression rates, have integral
combustion seals and coolant seals, eliminating the need for O-rings
and sealant. All gaskets are sold per pair. Dyno-Pak Bulk Gasket Sets
Gasket Pro Copper Titan Titan ICS Packaged for the engine builder. Sets include ten gaskets.
Description Bore Thickness Part No. Part No. Part No.
Part No. Description
Chevy 350-400 Small Block Chevy 265-400
350 4.060" .032" SCEP11063 — — SCE202 Distributor Gaskets
350 4.060" .043" SCEP11064 SCET11064 SCES11064 SCE1100-10 Timing Cover Gaskets
350 4.060" .050" — — SCES11065 SCE1101-10 Water Pump Gaskets (Sets)
SCE1102-10 Timing Cover Seals
350 4.060" .062" SCEP11066 — —
Rear Main Seals, 2-Pc.
400 4.155" .032" SCEP11153* — — SCE1104-10
Silicone, Rocket Block
400 4.155" .043" SCEP11154* SCET11154 SCES11154 Rear Main Seals,
SCE1105-10
400 4.155" .050" SCEP11155* — — 2-Pc. Silicone
400 4.155" .062" SCEP11156* — — SCE11090-10 Oil Pan, 1975-85 LH
400 4.155" .080" SCEP11158* — — Dipstick, Thick Ft. Seal
Oil Pan Gaskets, 86-Up
400 4.200" .043" SCEP11204* — — 1-Pc. Rear Main Seal, RH
SCE11092-10
400 4.200" .062" SCEP11206* — — Dipstick,
* SB Chevy 400 gaskets do not have steam holes between cylinders. Thick Ft. Pan Seal
Oil Pan Gasket
SCE recommends using 304 stainless steel wire to SCE11093-10
properly O-ring cylinder heads and block. O-rings For Rocket Block
do not need to be changed when installing new Oil Pan Gaskets, Crate
head gaskets. See below for O-ring wire. SCE11095-10 Engine, 2-Pc. Rear Main
Seal, RH And LH Dipstick
O-Ring Wire
SCE recommends 304 stainless wire to SB Chevy Timing Cover,
properly O-ring cylinder heads or block. O- Water Pump And Fuel Pump
rings do not need to e changed when installing
new head gaskets. Gasket Set SCE11100
Part No. Description Fits all 265-400 Chevys and includes timing
SCE31541 0.041" 304 Stainless Wire, 15' Roll cover, water pump and fuel pump gaskets.
SCE31542 0.041" Wire And Installation Kit
SB Chevy Oil Pans Gaskets
Accu-Seal Intake Gaskets Part No. Description
Available in standard Accu- SCE111090 Oil Pan Gasket, .090" Thick
Seal “E” and premium Accu- SCE111093 Oil Pan Gasket, Rocket Block
Seal Pro. Accu-Seal Pro
Gaskets have the added benefit of silicone beading around the ports
and water passages. Quick Change
Rear Axle Gaskets
Part No. Description Port Type Thk.
Small Block Chevy 265-400 Choose Accu-Seal “E” or reusable,
steel core Accu-Seal Pro gaskets.
SCE111118 Accu-Seal “E” 18°/1.265" x 2.180" 1/16"
Accu-Seal “E” Accu-Seal Pro
SCE111124 Accu-Seal “E” Pro Topline 14° 1/16" Description Part No. Part No.
SCE211102 Accu-Seal Pro 23°/1.32" x 2.19" 1/16" Quick Change Gasket SCE103 SCE203
Quick Change Gasket, Contoured — SCE204*
* Steel core

359
