Page 357 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Direct Mount Hubs SND1015-15F-9 Racing Wheels
Forged aluminum Hubs directly CNC, cold-spun wheel halves are cold
replace front wheel centers on formed over a two stage mandrel and
Superlite type spindles. Hubs are heat treated twice resulting in a perfect
sold in pairs with Timken bearings wheel. Bead locks are billet, not formed or
and races, seals, dust covers with welded. Six-pin centers are machined from billet
O-rings, studs and lug nuts. for maximum weight savings with splined centers are
Part No. Description cast from magnesium. Halves are polished and lock ring
Replacement Components is anodized. Include mud covers.
SNDS113 Lug Nut, 5/8"-11, Each Back
SNDS132 Bearing And Seal Kit, Pair Part No. Description Size Spacing
SND15-083-DN Direct Mount Wheel, No Beadlock 15" x 8" 3"
SND15-084-DN Direct Mount Wheel, No Beadlock 15" x 8" 4"
Shortie Spindles SNDS501 SND15-156-SI1 Splined Wheel, Inside Beadlock #1 15" x 15" 6"
Sander style aluminum spindles have tubular SND15-157-SI1 Splined Wheel, Inside Beadlock #1 15" x 15" 7"
spindle pins. Sold individually with spindle nuts, SND15-176-S02 Splined Wheel, Outside Beadlock #2 15" x 17" 6"
locking pins and washers. Use with SND1006 SND15-186-S02 Splined Wheel, Outside Beadlock #2 15" x 18" 6"
front hubs.
Part No. Description
Replacement Components
SNDS512 Spindle Nut And Washer Kit, Pair
SNDS514 King Pin Bushing, Sold Each(Must Be Honed After Installation) Wheel Accessories
Part No. Description
Tubular King Pins And Caps SND1-08 15" x 8" Wheel Half, No Beadlock
SND1020-15 Magnesium Splined Rear Wheel Center
Part No. Description SND1020-15F Forged Aluminum Splined Rear Wheel Center
Sprint Tubular King Pin, .859" Dia.,
SNDS167-1 SND15-010 15" 16-Bolt Beadlock Ring, #1 Type, No Mud Cover
Fits SNDS500 Or SNDS501 Spindles With SNDS167C Cap SND15-020 15" 16-Bolt Beadlock Ring, #2 Type, No Mud Cover
SNDS167-3 Same As SNDS167-1, But Oversize .869" Dia. SND15-021 15" 16-Bolt Beadlock Ring, #2 Type, With Mud Cover
SNDS167C Locking Cap, 1/2"-20 Threads SND15-022 Mud Cover, #2 Type, With Quick Fastener Button
SNDS167CB Locking Cap, 5/8"-18 Threads
Rear Cam Drive Components U-Joint Assemblies
Part No. Description U-joint Assembly eliminates over two pounds of rotating weight.
Cam Drive, Std. RH 9/16"-18 Threads,
SNDS202 Part No. Description
1" Long Body, 1-5/8" Overall Length SNDS304A Aluminum U-Joint Assembly
2.100" OD Cam Seal,
SNDS203 SNDS304AS Aluminum To Stell U-Joint Assembly
Includes Plate And Seal For SB Chevy
Birdcage Clevis
Front Brake Hat SND1055
Part No. Description
Steel W-Link Clevis, Lightweight aluminum Hat fits 12.18"
SNDS620-1 1/2" Shank, 3/8" Hole For Pin, diameter vented rotor. Should be used with
For Birdcages With A 1/2" Clevis Hole SNDS517 mounting stands, which mount to
Steel W-Link Clevis, the back side of the SND1006 hubs with 8 x
SNDS620 5/8" Shank, 3/8" Hole For Pin, 7.62" bolt pattern rotor.
For Birdcages With A 5/8" Clevis Hole
Tubular Torsion Bars
Front Rotor Mount Kit SNDS517
Kit includes 3 stands and 3 flat head bolts, both
Tubular torsion bars cut approximately 3 pounds and react more with 1/2"-20 threads.
quickly. All have 1-1/8" x 48-spline with 1" bushings and a 3/4" hole
thru.
Part No. Description
SNDS155-30-1000 1-1/8" Torsion Bar, 30" Long, 1.000" Bar Dia.
SNDS155-30-1025 1-1/8" Torsion Bar, 30" Long, 1.025" Bar Dia.
Front Mount Caliper Bracket
Tubular Driveshafts SNDS164-16-30 SND1054-2
Caliper bracket is engineered for use with
Sander SNDS501 or 2000 series spindles
Super strong, lightweight driveshafts have 16-10 splines and are and accepts 4-piston calipers with 5.25"
available in 30".
mounting. Sold each.
Torsion Bar Bushings
Part No. Description
SNDS148B Bronze, Fits 1-1/2" Tube With .120" Wall
SNDS149 Aluminum, Fits 1-1/2" Tube With .095" Wall
SNDS149B Bronze, Fits 1-1/2" Tube With .095" Wall
356
