CHASSIS Universal Seat Mount Kit Steering Shaft Tubing

Seamless D.O.M. tubing is 3/4" O.D.
ALL22110
1-1/2" dia. x .095" wall mild steel tubing
an excellent choice when building a steering assembly to
attaches to roll cage, to safely and effec- with .120" wall thickness making this
tively mount a seat. Use with Allstar roll connect steering wheel to steering box or rack and pinion.
cage kits. Kit is sold unassembled and ALL52132 oversized rod end is commonly used to support
requires welding. steering shaft. Consult sanctioning rules to verify proper
installation when building a steering assembly.
Lower Seat Mount ALL22190 ..... 5 Ft.
ALL22191 ..... 6 Ft.
ALL60070
Mount attaches through floor “Double D” Steering Shafts
pan to a bar or plate attached to Solid steel shaft has the appearance of two D‘s stacked
the left frame rail or roll cage for seat and anti-sub belt back to back when viewed from the end or simply a 3/4"
mounting. Mount is 2-3/4" tall and seat tabs are welded round shaft with flats on opposite sides. Often used with
at a 15° angle to the floor mounts.
stock type couplers, this shaft can be used in assemblies
without welding. Commonly connected to U-joints using
Seat Mount Brackets a set screw, the shaft should be dimple drilled to help pilot
Made from 1/8" thick mild steel. Upper set screws and help prevent the assembly from sliding
bracket is angled to fit against the back of apart. ALL52132 oversized rod end is commonly used to
ALL60032
most aluminum racing seats. Two-piece design support steering shaft. Consult sanctioning rules to verify
allows front-to-back and side-to-side adjust- ALL60033 proper installation when building a steering assembly.
ment. Upper mount brackets may be bolted ALL52175 ..... 24" Shaft
or welded. Lower mount welds to 1-1/2" or 1-3/4" ALL52176 ..... 30" Shaft
tubing. ALL52177 ..... 36" Shaft
ALL60032 ..... Upper, 2-Piece ALL52178 ..... 60" Shaft
ALL60033 ..... Lower ALL52179 ..... 72" Shaft

Double Shear Seat Belt Tab ALL60031 Steering Column Brackets
Bracket welds to chassis for solid seat belt mount Stamped-steel brackets weld to dash bars to create a
to the chassis, yet still able to pivot. Double shear mounting point for steering shaft when using a 3/4"
design provides twice the strength of a single tab oversized rod end. Brackets are 3-1/8" wide and available
style mount. Steel bracket accepts 1/2" hardware. in a variety of lengths to fit most applica-
tions. 4" and longer brackets are pre-
Floor Pedal Plate ALL54050 notched for 1-1/2" dash bars but are
easily modified to fit other size bars.
Weld-in pedal
plate is 23" x ALL52120 ..... 2-1/2" Long
5" x 1/8" and ALL52122 ..... 4" Long
speeds up ALL52124 ..... 8" Long
race car construction by providing the proper spacing for ALL52126 ..... 10" Long
mounting pedal/master cylinder assemblies.
Steering Shaft Rod End Mounting Tab
Hanging Brake Pedal Mount ALL52133
Gusseted weld-on tab provides an
ALL54060 NEW!
excellent mounting point for the
Welds to chassis to mount Wilwood and 3/4" oversized rod end (ALL52132) when
Tilton style hanging pedals. Notched to building custom steering shaft assem-
clear balance bar.
blies. Tab is designed to cradle into round
chassis tubing with built-in gussets adding
strength and reducing flex.
Related Item
ALL52132 ..... Oversized 3/4" Rod End Kit
Steering Quickener Bracket
ALL60028
Mounts all popular steering quickeners
including AFCO, Coleman, Howe and
others. Bracket has two holes, spaced 1-3/4" apart, and
may be welded to 1-1/2" or 1-3/4" dia. tubing.
