LIGHTWEIGHT SPRING CUP SHAW BEARING BIRDCAGES
Spring cup features a lightweight design. Steel birdcages, offered for Shaw or Skyrocket chassis, locate
Part No. Description on the inner race to reduce side loads. Double shear brackets
BSB7446-3 Lightweight Spring Cup offer increased strength. Sold complete with 3.008" bearing and
BSB7446-1 8" Jack Bolt, 1"-8 Threads hardware.
BSB7446-2 11" Jack Bolt, 1"-8 Threads Part No. Description
BSB7550L Shaw LH Birdcage
BEARING SWIVEL SPRING CUP BSB7550R Shaw RH Birdcage
Unique design allows spring cup to swivel in any
direction up to 15°, maintaining proper spring align- BSB7550L
ment throughout full A-arm travel. Cup is 2" tall and
includes a replaceable bearing.
Part No. Description BEARING BIRDCAGE
BSB7448 Bearing Swivel Spring Cup With Jack Bolt
BSB7448-1 Bearing Swivel Spring Cup Only Lightweight, yet rugged steel birdcage features a redesigned
hub that uses less bolts and offers more clearance. Unit, which
uses a 3.008" bearing, includes a single row of upper holes
FIFTH AND SIXTH COIL MOUNT and 3/4" holes in the lower for two links. May be used on left
BSB4062 or right side. Birdcage BSB7102 includes the addition of
Billet aluminum mount secures to 1-1/2" dia. round chassis an adjustable bottom slot, which allows for more
tubing, securing fifth and sixth coil assemblies. Sold complete steer in the car. Sold complete with shock
with quick pin for shock. mount, retainer ring and necessary hardware.
Part No. Description
BSB7100 Bearing Birdcage
Bearing Birdcage, BSB7100
BSB7102
Includes Adjustable Bottom Slot
Replacement/Accessory Components
SIXTH COIL ASSEMBLY BSB4065 BSB7011 Steel Shock Ring
BSB7017
Retainer Ring
Special sixth coil assembly allows it to swivel in all four BSB7550-4 90° Shock Mount, Eliminates Bind
directions, providing smooth suspension travel and even chain BSB7550-7 Clevis For 90° Shock Mount (BSB7550-4)
pressure. Sold complete with 1/2" rod end and 600 lb. spring. BSB7100-1 4-Link Plate
TWO-PIECE
BEARING BIRDCAGES
Two-bolt design birdcages allows quickly chang-
ing from floated to clamped mounting. Lightweight
XD SERIES STEEL BEARING BIRDCAGE steel birdcages use a large, 3.008" bearing and BSB8310-R
BSB7110 locate on the inner race for reduced side loads.
Sold complete with retaining rings and bushings.
New design allows the retaining ring to be mounted Part No. Description
directly against the race of the roller bearing. This helps BSB8310-L Two-Piece Birdcage, Left
spread the load on the bearing and makes the birdcage BSB8310-R Two-Piece Birdcage, Right
more stable. Two-piece design allows for easy repairs and
accepts 5/8” rod ends. Comes complete with shock
mount, retaining rings and rod end spacers.
Part No. Description BEARING LOCATOR KIT
Replacement Components BSB7320-4
BSB7110-1 Top 4-Link Plate Locator kit reduces friction on birdcage, allowing side
BSB7110-6 Lower 4-Link Plate loads to transmit to bearing. Sold as a set.
XD BEARING BIRDCAGE
New design, XD Bearing Birdcage provides TWO-LINK FOR NORTHERN
more forward and side bite, while also pre- SPORT MODS BSB7330
venting any possibility of bind between Engineered specifically for use on IMCA Northern Sport
bearings, birdcage parts or axle tube. Mods, two-link allows running various shock drops. Steel
Lightweight assembly is manufactured construction unit features a two-piece ring design that is
using high alloy, 1/2" steel plates with held in place with three 7/16" bolts. Two-link may be
a 3" overall width (4" overall with tack welded in place for added strength.
included retainer rings). Assemblies
accept 5/8" rod ends and are sold DOUBLE SHEAR TWO-LINK
complete with retainer rings and FOR NORTHERN SPORT MODS
bushings. May be purchased with
or without shock mounts. BSB7350
Without With Two-link, used on IMCA Sport Mods and other applications,
Shock Mounts Shock Mounts allows using 5", 6" and 7" shock drops. Double shear plate
Description Part No. Part No. design provides added strength and the ability to replace dam-
XD Bearing Birdcage, Left BSB8370-L BSB83702-L
XD Bearing Birdcage, Right BSB8370-R BSB83702-R aged parts. Two-piece, ring design includes (5) 3/8" bolts
that hold plate to ring.
