SLS SERIES SLM SERIES
STEEL SHOCK ABSORBERS LEFT REAR SHOCK ABSORBERS
Linear valved, SL mono tube gas filled shock absorbers are popular FOR MODIFIEDS
on late models and modifieds. The 2" O.D. plated steel bodies use 1.81" Specifically designed for installation on the left rear of popular UMP,
(46mm) pistons to deliver consistent, fade-free performance. Shocks are IMCA or USMTS Modifieds. SLM Series steel bodied, 2" O.D. shock in-
available in 7" and 9" strokes and may be converted to coil-overs. corporates a special, low bleed 1.81" (46mm) piston that creates a large
Extended Compressed Rebound Compression amount of damping at low shaft speeds, keeping the left rear suspension
Part No. Length Length Stroke Damping Damping up on the four-link bars longer for increased traction.
BILS7L-3-4S 20.00" 13.14" 7" 3 4
BILS7L-3-5S 20.00" 13.14" 7" 3 5 Part No. Extended Compressed Stroke Rebound Compression
Length
Length
Damping
Damping
BILS7L-4-2S 20.00" 13.14" 7" 4 2 BILS9L1.5-7M 23.44" 14.94" 9" 1.5 7
BILS7L-4-4S 20.00" 13.14" 7" 4 4 BILS9L-3-7M 23.44" 14.94" 9" 3 7
BILS7L-5-5S 20.00" 13.14" 7" 5 5 BILS9L-3-8M 23.44" 14.94" 9" 3 8
BILS7L-6-2S 20.00" 13.14" 7" 6 2
BILS9L-1.5-5S 23.44" 14.94" 9" 1.5 5 XVS SERIES
BILS9L-2-2S 23.44" 14.94" 9" 2 2
BILS9L-3-3S 23.44" 14.94" 9" 3 3 STEEL SHOCK ABSORBERS
BILS9L-3-5S 23.44" 14.94" 9" 3 5 Well suited to modifieds, late models, etc., 2" steel body
BILS9L-3-6S 23.44" 14.94" 9" 3 6 shocks with 1.81" (46mm) pistons are engineered to deliver consistent, fade-
BILS9L-4-1.5S 23.44" 14.94" 9" 4 1.5 free performance using an extreme volume nitrogen bulb. Zinc-plated shocks,
BILS9L-4-4S 23.44" 14.94" 9" 4 4 which are available with linear or digressive piston, are fully rebuildable and
BILS9L-5-5S 23.44" 14.94" 9" 5 5 may be disassembled and reassembled for quick repairs or valving chang-
es.
Ext. Comp.
1-5/8" LIGHTWEIGHT Part No. Description Length Length Stroke
STEEL SHOCK ABSORBERS Front Applications
6" XVS,
Affordable 1-5/8" O.D. monotube gas shocks use 36mm pistons to BILX6P-10-2COBB 10-2COB Valving, ACV 19.30" 13.35" 6"
offer consistent, fade-free performance for stock cars, modifieds and 6" XVS,
other open wheel cars. All have "off the shelf" valving and are avail- BILX6P-8-2COBB 8-2COB Valving, ACV 19.30" 13.35" 6"
able with 6", 7" or 8" strokes. All shocks include rod ends and may be 7" XVS,
converted to coil-overs. BILX7P-10-2COB 10-2COB Valving 20.15" 13.35" 7"
Extended Compressed Rebound Compression BILX7P-3545 7" XVS, 3545 Valving 20.15" 13.35" 7"
Part No. Length Length Stroke Damping Damping BILX7P-5050 7" XVS, 5050 Valving 20.15" 13.35" 7"
BILS6G1030 17.00" 11.00" 6" 1 3 BILX7P-6040 7" XVS, 6040 Valving 20.15" 13.35" 7"
BILS6G2040 17.00" 11.00" 6" 2 4 BILX7P-8-2COB 7" XVS, 8-2COB Valving 20.15" 13.35" 7"
BILS6G3010 17.00" 11.00" 6" 3 1 Rear Applications
BILS6G3030 17.00" 11.00" 6" 3 3 7.5" XVS,
BILS6G4545 17.00" 11.00" 6" 4-1/2 4-1/2 BILX8P-3.5-1S-B 3.5-1S Valving, ACV 22.77" 15.24" 7.5"
BILS6G5555 17.00" 11.00" 6" 5-1/2 5-1/2 7.5" XVS,
BILS7G1090 20.00" 12.00" 7" 1 9 BILX8P-3030-B 3030 Valving, ACV 22.77" 15.24" 7.5"
BILS7G2040 20.00" 12.00" 7" 2 4 7.5" XVS,
BILS7G3030 20.00" 12.00" 7" 3 3 BILX8P-4040-B 4040 Valving, ACV 22.77" 15.24" 7.5"
BILS7G3050 20.00" 12.00" 7" 3 5 7.5" XVS,
BILS7G3060 20.00" 12.00" 7" 3 6 BILX8P-4-2S-B 4-2S Valving, ACV 22.77" 15.24" 7.5"
BILS7G3535 20.00" 12.00" 7" 3-1/2 3-1/2 BILX9P-1.5-5M 9" XVS, 1.5-5M Valving 23.76" 15.24" 9"
BILS7G4545 20.00" 12.00" 7" 4-1/2 4-1/2 BILX9P-3.5-1S 9" XVS, 3.5-1S Valving 23.76" 15.24" 9"
BILS7G5555 20.00" 12.00" 7" 5-1/2 5-1/2 BILX9P-3030 9" XVS, 3030 Valving 23.76" 15.24" 9"
BILS7G6020 20.00" 12.00" 7" 6 2 BILX9P-3050 9" XVS, 3050 Valving 23.76" 15.24" 9"
BILS7G6565 20.00" 12.00" 7" 6-1/2 6-1/2 BILX9P-3-7M 9" XVS, 3-7M Valving 23.76" 15.24" 9"
BILS8M3030 21.90" 13.90" 8" 3 3 9" XVS Valving,
BILS8M4040 21.90" 13.90" 8" 4 4 BILX9P-4040 4040 Valving 23.76" 15.24" 9"
BILS8M5030 21.90" 13.90" 8" 5 3 BILX9P-4-2S 9" XVS, 4-2S Valving 23.76" 15.24" 9"
Notes: S8M series shocks have a 17.9" approximate mounting height, but
may be used to replace 9" stroke shock absorbers in most applications.
On four-bar late models and modifieds that hyper extend the left rear
shock on corner exit, a S9Z series may be required to prevent the shock XVS SERIES “KIT FORM”
from “topping” out. Lengths include rod ends measured center-to-center.
STEEL SHOCK ABSORBERS
XVS Series shock absorbers are also offered in kit form, requiring
valving and filling prior to use.
Ext. Comp.
Part No. Description Length Length Stroke
6" XVS
XVS SERIES SHOCKS BILXVS-KIT-6DB* Digressive Shock 19.30" 13.35" 6"
When changing shocks over to use the optional Schrader valve, care must be 7" XVS
taken when removing the nitrogen chamber plug due to high gas pressure. Use BILXVS-KIT-7D Digressive Shock 20.15" 13.35" 7"
all safety precautions including safety glasses, face shield and gloves. Begin by BILXVS-KIT-7L 7" XVS Linear Shock 20.15" 13.35" 7"
inserting a 3/16” Allen wrench into the plug. Slowly loosen the plug in 1/4 turn 9" XVS
increments, while rocking it side-to-side until gas is heard escaping. Continue BILXVS-KIT-9D Digressive Shock 23.76" 15.24" 9"
by slowly loosening the plug until you no longer hear gas escaping. The plug BILXVS-KIT-9L 9" XVS Linear Shock 23.76" 15.24" 9"
may then be removed safely. * Shock kit includes base valve.
